PDP TV Service Manual
Hisense confidential
9
Block Diagram
The signal board is composed by the main board .The main chip for video decoder is
MST9E19A produced by MSTAR co., ltd.
signal processing diagram
key
/
remote
S
_video
AV
input
3 sound
input
RF
TDQ-6FT/
W126H
SAW
HS9457
HS6274
IF
TDA 9886
HDMI
signal
PC
signal
YPBPR
signal
MST
9E19
A
LG
PDP32F1
Plasma
display
/
sound
output
E
arphone
amp
LM833
S
ound amp
MP7722
FLASH
earphone
