Installing your new appliance
Refrigerator Door Removal
In case your home access door is too
narrow for the refrigerator to pass
through, remove the refrigerator doors
and drawers.
Tools you will need(Not provided):
Allen Wrench (5/32'', 4mm)
Philips Screwdriver
Wrench (5/16'', 8mm)
2. Remove the screws(2) fixed on the
upper hinges with a wrench(5/16'', 8mm)
and the ground screw(3) attached to
the hinge with Phillips(+) screwdriver.
Remove the upper left and right door
hinges(4).
1. With the door closed, remove the 3
screws holding the top cover (1) with
Philips(+) screwdriver, and then remove
the top cover.
3. Use both hands to open the door
more than 90°. Lift it up and take it off.
4. Remove the screws(5) fixed on the
middle hinges with a allen
wrench(5/32'', 4mm) and the screw(6)
fixed on the middle hinges with
Phillips(+) screwdriver. Remove the
middle left and right hinges(7).
1
2
3
4
6
5
7
08
