7. Place the lower door on a smooth
surface with its panel upwards.
Change the handle to the right side
according to step 5. Loose screws⑦，
detach part⑥and part⑤.Turn part⑤by
180°and then install part⑤and part⑥to
corresponding position on left side
together with screws⑦.
② Special self-tapping screws
③ Handle
① Handle covers
④ Screw hole covers
⑤ Door holder
⑥ Stop block
⑦ Self-tapping screws
8. Change screw hole covers on
middle cover plate from left to right (as
shown in figure below).
9. Place refrigerator flatwise, remove
part③ and then loose screws④.
Remove part ② and part①.
10. Screw out lower hinge, change it to
the near hole site, and then screw up
and mount washer.
② Front foot fixed board
④ Self-tapping screws
③ Adjustable bottom feet part
① Lower hinge part（right）
Note: washer may
stick to lower door.
washer
Lower hinge part (left)
Note: washer may
stick to lower door.
Washer
11.Just remount to the step 9,change
part①to left and part②to right and then
fix them with screws④. Finally install
part③.
12. Move the lower door and adjust its
position to align lower hole site and
upper hinge axis. Turn the middle
hinge by 180, change the washer on
the axis to the upper side, adjust the
middle hinge to the appropriate
position and then install
it.
13. Screw out The upper hinge axis,
turn the upper hinge over and fix axis
on it. Then place it at side for use.
1
2
Hisense Refrigerator
