Hisense RF632N4WFE User Manual

Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct sunlight
,
rain or frost. Stand the appliance away
from heat sources such as stoves, fires or
heaters.
Adjustable bottom feet
10-15mm
A
C
A
A
B
C
Adjustable bottom
feet
Front roller
Rear roller
B
Leveling of appliance
For sufficient leveling and air circulating
in the lower rear section of the
appliance, the bottom feet may need to
be adjusted.You can adjust them
manually by hand or by using a suitable
spanner.
To allow the doors to self-close, tilt the
top backwards by 10-15mm.
1. The freezer compartment is provided
with an upper drawer, a lower drawer ,
two trays and an ice box;
2. Open the freezer door; Pull up the
adjusting block (A) of the slide guides,
and pull out the freezer door drawer (A)
to the final position.
1. The freezer compartment is provided
with an upper drawer, a lower drawer ,
two trays and an ice box;
2. Open the freezer door; Pull up the
adjusting block (A) of the slide guides,
and pull out the freezer door drawer (A)
to the final position.
Disassembling the freezer drawer
Disassembling the freezer drawer
3. Take out the tray (B) by lifting it up in the
direction of the arrow.
4. Remove the lower freezer drawer (C) by
lifting it up.
13

Hisense RF632N4WFE Specifications

General

Control type	Touch
Display type	LED
Product color	Black
Product design	French door
Built-in display	-
Shelves material	Tempered glass
Custom panel-ready	Yes
Appliance placement	Freestanding
Anti-bacterial seal	No
Fridge net capacity	336 L
Fridge door balconies	6
Number of vegetable drawers	1
Fridge number of shelves/baskets	2
Noise level	38 dB
Certification	CE, UKCA
Climate class	SN-T
Cooling system	Ventilated
Water supply type	Water tank
Total net capacity	485 L
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	11 kg/24h
Freezer net capacity	149 L
Storage time during power failure	10 h
Cord length	2 m
Connected load	0 W
Power plug type	Type G
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	295 kWh
Country of origin	China
Package depth	738 mm
Package width	750 mm
Package height	2111 mm
Package weight	101000 g

Weight and Dimensions

Depth	694 mm
Width	700 mm
Height	2000 mm
Weight	92000 g
