Hisense RS818N4TIC User Manual

5. Using the Ice Bucket
If you want to remove the Ice Bucket:
Please hold the handle as shown in
the figure below. Then lift up and pull
the Ice Bucket out slowly to prevent
damage.
Note!
When the ice maker dumps ice into
the bucket, any sounds you hear are
part of normal operation.
If you do not dispense ice for a
long periods of time, Ice may clump
in the Ice Bucket. If this occurs,
please remove all the ice and empty
the bucket.
If ice doesn’t come out, please
check for any ice stuck in the chute
and remove it. Or pull out the Ice
Bucket and check for any ice cubes
clump, then remove them.
Ice chute
Ice Maker Cover
Ice Bucket
If you are going on a long vacation
or business trip and won’t be using
the ice dispensers for period of time,
please close the water valve to
prevent leaks.
①L the Ice Bucketift up
②Pull the Ice Bucket out slowly
Removing Steps:
B
B’
A
A’
When you put it back, please make
sure the two side(B&B’) of Ice Bucket
is wedged into the buckles(A&A’).
①
②
Installing Steps:
①
the two side(B&B’) of Ice Bucket
wedge into the buckles(A&A’).
②Pull the Ice Bucket down, and make
sure the Ice Bucket is held the bracket
firmly.
Push the Ice Bucket up, and make
①
②
Pull out
A
B
A
B
Push up
If the refrigerator has been power-
off too long,the ice in the bucket will
melt ,and the water will flow out of the
refrigerator to the floor.To avoid
this,you should remove all the ice in
the bucket .
21

Hisense RS818N4TIC Specifications

General

Star rating	4*
Freezer position	Side-placed
Freezing capacity	11 kg/24h
Fast freeze function	Yes
Freezer net capacity	215 L
Freezer number of doors	1
Freezer temperature (min)	-18 °C
Freezer number of shelves/baskets	4
Storage time during power failure	5.5 h
Freezer number of vegetable drawers	2
Door opening angle	130 °
Cord length	2 m
Temperature alarm	No
Control type	Touch
Display type	LED
Product color	Stainless steel
Product design	American door
Appliance placement	Freestanding
Fresh zone compartment	-
Package depth	775 mm
Package width	978 mm
Package height	1860 mm
Package weight	128000 g
AC input voltage	220-240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	221 kWh
Noise level	36 dB
Certification	CE, UKCA
Climate class	N-T
Water supply type	Water tank
Total net capacity	632 L
Fridge net capacity	417 L
Fridge number of shelves/baskets	3

Weight and Dimensions

Depth	730 mm
Width	910 mm
Height	1790 mm
Weight	118000 g
Width with door open	1563 mm
