Hisense RT417N4DC1 User Manual

6. Place the lower door on a
smooth surface with its
panel upwards.Loose
screws detach part
Then install part to
corresponding position on
left side together with
screws
②， ①.
①
②.
②-Self tapping screws
① Stop block
①
②
7. Change screw hole
covers on middle cover
plate from left to right (as
shown in figure below).
8.Place refrigerator flatwise,
remove part and then
loose screws Remove
part and part
③
④.
②①.
Note: washer may
stick to lower door.
washer
② Front foot fixed board
④ Self tapping screws-
③ Adjustable bottom feet part
① Lower hinge part right（）
9. Screw out lower hinge,
change it to the near hole
site, and then screw up and
mount washer.
10. Just remount to the step
8,change part to left and
part to right and then fix
them with screws
Finally install part
①
②
④.
③.
Lower hinge part (left)
11. Move the lower door
and adjust its position to
align lower hole site and
upper hinge axis. Turn the
middle hinge by 180,
change the washer on the
axis to the upper side,
adjust the middle hinge to
the appropriate position and
then install it.
Hisense Refrig erator
10
