5K320 SATA OEM Specification
82
Word Content
0 0002h Data Structure revision
1 Multiword DMA modes supported
15-3
Reserved
2
1 = Multiword DMA mode 2 and below are supported
1
1 = Multiword DMA mode 1 and below are supported
0
1 = Multiword DMA mode 0 is supported
2 Ultra DMA modes supported
15-6
Reserved
5
1 = Ultra DMA mode 5 and below are supported
4
1 = Ultra DMA mode 4 and below are supported
3
1 = Ultra DMA mode 3 and below are supported
2
1 = Ultra DMA mode 2 and below are supported
1
1 = Ultra DMA mode 1 and below are supported
0
1 = Ultra DMA mode 0 is supported
3-6 Maximum LBA address
7 Command set/feature set supported
15-9
Reserved
8
1 = 48-bit Addressing feature set supported
7
1 = Host Protected Area feature set supported
6
1 = Automatic acoustic management supported
5
Reserved
4
1 = Power-Up in Standby feature set supported
3
1 = Security feature set supported
2
1 = SMART error log supported
1
1 = SMART self-test supported
0
1 = SMART feature set supported
8 SATA feature
15-5
Reserved
4
1 = Software setting preservation supported
3
Reserved
2
1 = Interface power management supported
1
1 = Non-zero buffer offset in DMA Setup FIS supported
0
1 = Native command queuing supported
9-254 Reserved
255 Integrity word <Note .>
15-8 Checksum
7-0 Signature (A5h)
Table 46 Device Configuration Overlay Data structure
Note.
Bits 7:0 of this word contain the value A5h. Bits 15:8 of this word contain the data structure
checksum. The data structure checksum is the two’s complement of the sum of all byte in words 0
through 254 and the byte consisting of bits 7:0 of word 255. Each byte is added with unsigned
arithmetic, and overflow is ignored. The sum of all bytes is zero when the checksum is correct.
