HMCS44C,HMCS44CL-------------------------------------------------------
•
Accumulator
(A; A Register) and Carry F/F
(C)
The result
of
the Arithmetic
Logic
Unit (ALU) operation
(4
bits) and the overflow
of
the ALU are loaded into the accumula-
tor and the Carry F/F. The Carry
F/F
can be set, reset or tested.
Combination
of
the accumulator and the Carry
F/F
can be right
or left rotated. The accumulator
is
the main register for
ALU
op-
eration and the Carry
F/F
is
used to store the overflow generated
by
ALU
operation when the calculation of
two
or more digits (4
bits/digit)
is
performed.
• 8 Register (8)
The result
of
ALU
operation
(4
bits)
is
loaded into this regis-
ter. The B register
is
used as a sub-accumulator
to
stack data
temporarily and also used
as
a counter.
• X Register (X)
The result
of
ALU
operation
(4
bits)
'is
loaded into this regis-
ter. The X register has exchangeability for the
SPX
register. The
X register addresses the RAM
file
and
is
composed of 4-bit regis-
ter.
• SPX RegilJ,ter (SPX)
The
SPX
register has exchangeability for the X register.
The
SPX
register
is
used to stack the X register and expand
the addressing system of RAM
in
combination with the X regis-
ter.
It
is
composed
of
4-bit register.
• V Register (V)
The result
of
ALU operation
(4
bits)
is
loaded into this regis-
ter. The Y register has exchangeability for the
SPY
register. The
Y register can calculate itself simultaneously with transferring
data
by
the bus lines, which
is
usable for the calculation of
two
or more digits
(4
bits/digit). The Y register addresses the RAM
digit and I-bit Discrete
I/O.
• SPY Register (SPV)
The
SPY
register has exchangeability for the Y register. The
SPY
register
is
used to stack the Y register and expand the ad-
dressing system of RAM and I-bit Discrete I/O
in
combination
with the
Y register.
LRA.
LRB
[
Instruction
LAR.
LBR
[
Instruction
-
-
----
One Instruction
Cycle
---..
Rn
Output
Instruction
Rn
Pattern Instruction
R2.R3
• INPUT/OUTPUT
•
4-bit
Data
Input/Output
Channel
(R)
The HMCS44C has four 4-bit Data I/O Common Channels
(RO,
RI,
R2, R3).
The 4-bit registers (Data
I/O Register) are attached to
RI,
R2
and
R3
channels.
Each channel
is
directly addressed
by
the operand p of input!
output instruction.
The data
is
transferred from the accumulator and the B regis-
ter to the Data I/O Registers
RO
to
R3
via
the bus lines. Pattern
instruction enables the patterns of ROM to be taken into the
Data
I/O Registers
R2
and
R3.
Input instruction enables the 4-bit data to be sent to the
ac-
cumulator and the B register from
RO
to
R3.
Note that, since the
Data
I/O Register output
is
directly connected to the pin even
during execution
of
input instruction, the input data
is
wired
logic
of
the Data I/O Register output and the
pin
input.
Therefore, the Data
I/O Register should be set
to
15
(all
bits
of
the Data I/O Register
is
"I")
not to affect the
pin
input be-
fore execution
of
input instruction.
The block diagram
is
shown
in
Figure
12.
The 1/0 timing
is
shown
in
Figure
13.
Output Function
r--------
--,
I
Rn3
Rn2
Data
Rnl
RnO
Reset
Function
Figure 12 4-bit Data
I/O
Block Diagram
(second cycle)
Rn
Input
r--
Instruction
Rn
Sampling Clock
Figure 13 4-bit Data
I/O
Timing
•
'-bit
Discrete
Input/Output
Common
Terminals (D)
The HMCS44C has
16
I-bit Discrete I/O Common Terminals.
The I-bit Discrete
I/O Common Terminal consists
of
a I-bit
latch and an
I/O common pin.
The I-bit Discrete
I/O
is
addressed
by
the Y register. The ad-
dressed latch can be set or reset
by
output instruction and
"0"
50
and
"1"
a level can
be
tested with the addressed pin
by
input in-
struction.
Note that, since the latch output
is
directly connected to the
pin even during execution
of
input instruction, the input data
is
wired
logic
of
the latch output and the pin input. Therefore, the
latch should
be
set to
"1"
not to affect the pin input before ex-
