HMCS44C,HMCS44CL--------------------------------------------------------
Data
Bus
TF: Set has priority over the reset.
Interrupt request
of
Timer/Counter
Clear
'-4-
__________
INT1
Pulse
Clock
(100kHz
typo
Instruction
Frequency)
Figure 1 7 Timer /Counter Block Diagram
Table 3 Timer
Range
Specified
Number
of
Specified Number
of
Time
(ms)
Time (ms)
Vah,Je
cycles Value cycles
0
1,024
10.24
8
512
5.12
1
960
9.60
9
448
4.48
2
896
8.96
10
384
3.84
3
832
8.32
11
320
3.20
4
768
7.68
12
256
2.56
5
704
7.04
13
192
1.92
6
640
6.40
14
128
1.28
7
576
5.76
15
64
0.64
[NOTE] Time
is
based on instruction frequency 100kHz. (one instruction cycle = lOps)
Figure
18
The Pulse Width
of
the INTI pin in
the Counter Mode
• INTERRUPT
The HMCS44C can be interrupted
in
two
different
ways:
through the external interrupt input pins
(INTo,
INTI) and the
timer/counter interrupt request. When any interrupt occurs, pro-
cessing
is
suspended, the Status
F/F
is
unchanged, the present
program counter
is
pushed onto the stack STl and the contents
of
the stacks
STl,
ST2
and
ST3
are pushed onto the stacks ST2,
STJ and
ST4
respectively. At that time,
the
Interrupt Enable
F/F
(I/E)
is
set and the address jumps to a fixed destination (Inter-
rupt Address), and then the interrupt routine
is
executed. Stack-
ing the registers other than the program counter must be per-
formed
by
the program. The interrupt routine must end with
RTNI (Return Interrupt) instruction which sets the
liE
F/F
si-
multaneously with the RTN instruction.
The Interrupt Address:
Input Interrupt Address
.....
1 Page 3 F Address
Timer/Counter Interrupt Address
.....
o Page 3F Address
The input interrupt has priority over the timer/counter inter-
rupt.
The
INTo
and
INTI
pin have an interrupt request function.
52
Each terminal consists
of
a circuit which generates leading
pulse and the interrupt mask
F/F
(lFO,
IF!). An interrupt
is
enabled (unmasked) when the IFO'
F/F
or IFI
F/F
is
reset.
When the
INTo
or
INTI
pin changes from
"0"
to
"I"
(from
"Low"
level to
"High"
lev~I),
a leading pulse
is
generated to
produce an interrupt request. At the same time, the
IFO
F/F
or
IFI
F/F
is
set. When the
IFO
F/F
or IFI
F/F
is
set, the interrupt
masking for the pin
will
result. (If a leading pulse
is
generated,
no interrupt request occurs.)
An interrupt request generated
by
the leading pulse
is
latched
into the input interrupt request
F/F
(I1RI) on the input side. If
the Interrupt Enable F
/F
(I/E)
is
"1"
(Interrupt Enable State),
an interrupt occurs immediately and the IIRI
F/F
and the
liE
F/
F are reset. If the
liE
F/F
is
"0"
(Interrupt Disable State), the II
RI
F/F
is
held at
"I"
until the HMCS44C gets into the Interrupt
Enable State.
The
IFO
F/F,
the IFI
F/F,
the
INTo
pin and the
INTI
pin can
be tested
by
interrupt instruction. Therefore, the
INTo
and the
INTI
can be used as additional input pins with latches.
The
INTo
pin and
INTI
pin can be provided with Pull up
MOS
using a mask option as shown
in
Figure
19.
An interrupt request from the timer/counter
is
latched into
the timer interrupt request
F/F
(I/RT). The succeeding opera-
tions are the same as an interrupt from the input.
Only the ex-
ception
is
that, since an interrupt from the input precedes a
timer/counter interrupt, the input interrupt occurs if both the II
RI
F/F
and the
I1RT
F/F
are
"I"
(when the input interrupt and
the timer/counter interrupts are generated simultaneously). Dur-
ing this processing, the IIRT
F/F
remains
"I".
The timer/coun-
ter interrupt can be implemented after the input interrupt pro-
cessing
is
achieved.
The interrupt circuit block diagram
is
shown
in
Figure
20.
