Leveling the washing machine
WARNING
！
1 2 3
4
Connect Water Supply Hose
WARNING
！
1
2
3
4
1
2
9
Installation
● The lock nuts on all four feet must be screwed tightly against the housing.
1. Check if the legs are closely attached to the cabinet. If not, please turn them to
their original positions tighten the nuts.
2. Loosen the lock nut turn the feet until it closely contacts with the floor.
3. Adjust the legs and lock them with a spanner, make sure the machine is steady.
Raise
Lower
Lock nut
foot
● To prevent leakage or water damage, follow the instructions in this chapter.
Do not kink, crush, modify or sever water inlet hose.
●
For the model equips hot valve, connect it to hot water tap with hot water supply
●
hose. Energy consumption will decrease automatically for some program.
Connect the inlet pipe as indicated. There are two ways to connect the inlet pipe.
Connection between ordinary tap and inlet hose.
clamp nut
Loosen clamp nut and
four bolts
Tighten clamp nut
Press slide bushing,
insert inlet hose into
connecting base
Slide Bushing
Connection finished
Connection between screw tap and inlet hose.
Tap with threads and inlet hose
Slide Bushing
Special tap for washing machine
● Check the alignment of the washing machine with level, and adjust the feet if it’s aligned.
