15
English
Gloves for handling saw blades (saw blades shall
be carried in a holder wherever practicable) and
rough material.
15. The operator is adequately trained in the use,
adjustment and operation of the machine.
16. Refrain from removing any cut-offs or other parts
of the workpiece from the cutting area whilst the
machine is running and the saw head is not in the
rest position.
17. Never use the slide compound miter saw with its
lower guard locked in the open position.
18. Ensure that the lower guard moves smoothly.
19. Do not use the saw without guards in position, in
good working order and properly maintained.
20. Use correctly sharpened saw blades. Observe the
maximum speed marked on the saw blade.
21. Do not use saw blades which are damaged or
deformed.
22. Do not use saw blades manufactured from high
speed steel.
23. Use only saw blades recommended by HITACHI.
Use of saw blade comply with EN847-1.
24. The saw blades should be from 290 mm to 305 mm
external diameter ranges.
25. Select the correct saw blade for the material to be
cut.
26. Never operate the slide compound miter saw with
the saw blade turned upward or to the side.
27. Ensure that the workpiece is free of foreign matter
such as nails.
28. Replace the table insert when worn.
29. Do not use the saw to cut other than aluminium,
wood or similar materials.
30. Do not use the saw to cut other materials than those
recommended by the manufacturer.
31. Blade replacement procedure, including the method
for repositioning and a warning that this must be
carried out correctly.
32. Connect the slide compound miter saw to a dust
collecting device when sawing wood.
33. Take care when slotting.
34. When transporting or carrying the tool, do not grasp
the holder. Grasp the handle instead of the holder.
35. Start cutting only after motor revolution reaches
maximum speed.
36. Promptly cut OFF the switch when abnormality
observed.
37. Shut off power and wait for saw blade to stop before
servicing or adjusting tool.
38. During a miter or bevel cut the blade should not be
lifted until it has stopped rotation completely.
39. During slide cutting operation, the saw must be
pushed and slided away from the operator.
40. Take all the possibility of residual risks in cutting
operation into your consideration, such as the laser
radiation to your eyes, the inadvertent access to
moving parts on slide mechanical parts on machine
and so on.
SPECIFICATIONS
* Be sure to check the nameplate on product as it is subject to change by areas.
0° 105 mm × 312 mm
Miter 45° 105 mm × 220 mm
Left 45° 68 mm × 312 mm
Bevel
Right 45° 43 mm × 312 mm
Bevel (Left) 45° + Miter 45°
68 mm × 220 mm
Compound Bevel (Right) 45° + Miter (Left)
31° 43 mm × 265 mm
Bevel (Right) 45° + Miter (Right)
45° 43 mm × 220 mm
Saw Blade Dimensions (oD × iD × Thickness) 305 mm × 30 mm × 2.3 mm
Miter Cutting Angle Right 0° – 57°, Left 0° – 46°
Bevel Cutting Angle Right and Left 0° – 45°
Compound Cutting Angle
Bevel (Left) 0° – 45° Miter (Left) 0° – 45°, Miter (Right) 0° – 31°
Bevel (Right) 0° – 45° Miter (Right) 0° – 45°, Miter (Left) 0° – 31°
Voltage (by areas)* (110 V, 230 V)
Power Input* 1520 W
No-Load Speed 4000 min
–1
Machine Dimensions (Width × Depth × Height) 595 mm × 930 mm × 710 mm
Model C12LSH C12RSH
Weight (Net) 30 kg 29 kg
Digital Display Precision ±0.5° Yes No
Maximum output Po<3 mW Class Laser Product
(Iambda) 654 nm
Laser medium Laser Diode
Laser Marker
Max. Cutting
Capacity
Height × Width
01Eng_C12LSH_WE_7L 1/23/07, 10:1815
