22
English
SPECIFICATIONS
* Be sure to check the nameplate on product as it is subject to change by areas.
STANDARD ACCESSORIES
(1) Cut-offf wheel ............................................................ 1
(2) Hex. bar wrench .......................................................1
APPLICATION
Cutting of various metallic materials such as pipes,
round bars, shaped steel and siding board.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized
conforms to the power requirements specified on
the product nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, which could cause
a serious accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Install the machine on a level flat place, and keep
it in a stable condition. Prior to shipping, the
equipment is subjected to a rigid factory inspection
to prevent electric shocks during operation.
5. Since movable portions are secured by tension of
a chain while in transit, remove the chain from
the chain hook by slightly depressing the switch
handle.
6. Ascertain that all cut-off wheels are in perfect
condition, and do not display scars and cracks.
7. Although they have been fully clamped at the
factory prior to delivery, reclamp the clamping
nuts securely for safety.
8. Possible accidents such as a cracked cut-off wheel
is prevented by this protective cover (wheel cover).
Although it has been fully clamped at the factory
prior to delivery, securely reclamp the mounting
screws for safety.
9. When replacing the cut-off wheel, ensure that the
replacement cutting wheel has a designed
circumferential speed in excess of 4800 m/min.
10. Ensure that the bar spanner used for tightening
or removing the cut-off wheel is not attached to
the machine.
11. Check that the work piece is properly supported.
Ensure that the material is securely fastened with
the vise. If it is not, a serious accident could be
caused if the material comes loose or the cut-off
wheel breaks during operation.
12. Ensure that the abrasive wheel is correctly fitted
and tightened before use and run the machine at
no-load for 30s in safe position, stop immediately
if there is a considerable vibration or if other
defects are detected. If this condition occurs, check
the machine to determine the cause.
13. Rotate the cut-off wheel to inspect any facial
deflection. A heavy deflection will cause the cut-
off wheel to shift.
14. Ensure that ventilation openings are kept clear
when working in dusty conditions. If it should
become necessary to clear dust, first disconnect
the machine from the mains supply.
CUTTING PROCEDURES
CAUTION
It is dangerous to remove or install the workpiece while
the cut-off wheel turning.
1. Operating the switch
The switch is switched on by manually pulling the
trigger and cut off by releasing the trigger to the
original location. The switch will not operate unless
the stopper has been pushed in.
2. Cutting
(1) Rotate the cut-off wheel, gently press down the
handle, and bring the cut-off wheel close to the
cutting material.
9. Ensure that mounted wheel are fitted in accordance
with the manufacture’s instructions.
10. Do never use the machine without the guard in
place.
11. Do not saw blade.
12. Do not use the machine in explosive atmospheres
and environments where sparks could fire,
explosion etc.
Voltage (by areas)*
Input
Max. cutting dimensions
90° 115 mm × 130 mm 70 mm × 235 mm
Height × width
45° 100 mm × 106 mm
Cut-off wheel ø355 × ø25.4 × 4 mm (Reinforced resinoid cut-off wheel)
No-Load Speed 3800 min
-1
Max. working peripheral speed 4800 m/min
Weight 17 kg
(110V, 115V, 120V, 127V) (230V, 240V)
1640W* 2000W*
