CP-AX3503 LCD Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories
Supplied
Accessories
Remote control, power cord,
computer cable, user's manual,
network manual
Optional
Accessories
HAS-WM03 wall mount, wall plates,
wall adapter, USBWL11N USB wireless
adapter, MS-1 wired and MS-1WL
wireless multifunction switchers,
TT-03 tabletop stand
Replacement Parts
Lamp DT01411 with filter
Remote Control HL03033
Filter UX37191
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution XGA 1024 x 768
White Light Output 3,600 ANSI lumens
Color Light Output 3,600 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 / 16:9 and 16:10 compatible
Contrast Ratio 5000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
0.2 : 1 from edge of projector to screen
0.3 : 1 from mirror cover to screen
Focus Distance 15" - 26" from mirror cover to screen
Display Size 60" - 100"
Lens & Operation
Lens F = 1.8, f = 4.21 mm
Lamp Wattage 250W
Expected Lamp Life* Approximately 2,500 hours (standard mode)
4,000 hours (Eco mode)
Expected Filter Life** Approximately 4,000 hours
Speaker Output 16W x 1
Keystone H and V: +/- 5º
Compatibility
Computer VGA, SVGA, XGA, WXGA, WXGA+/SXGA/WSXGA+/UXGA
(compressed), MAC 16"
H-Sync 15 kHz - 106 kHz
V-Sync 50 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 2 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1 (shared with computer in 2)
Video Input
S-Video N/A
Composite Video RCA jack x 1
Component Video 15-pin D-sub x 2 (shared with computer in 1/2)
Audio Input 3.5 mm stereo mini jack x 1, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
Audio Output 3.5 mm stereo mini jack x 1
Network LAN Wired RJ-45 port (10 base-T / 100 base-TX)
Network LAN Wireless USB-A, IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less presentation, wireless adapter)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 360W
Operating Temperature 32ºF - 104ºF (0ºC - 40ºC)
Dimensions (W x D x H) 14.8" x 14.2" x 5.4" (excluding protruding parts)
Weight Approximately 9.5 lbs
Approvals UL 60950-1 / cUL, FCC part 15 subpart B Class B
Warranty 3 year limited parts and labor
Extended Service Contract available (additional cost)
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Diagonal Distance from
edge of projector
to screen
Distance from
mirror cover
to screen
60 4.1 15.2
70 6.7 17.8
80 9.3 20.4
90 11.9 23.0
100 14.5 25.6
Throw Ratio: (distance : width)
0.2 : 1 from edge of projector
0.3 : 1 from mirror cover
CP-AX3503
Hitachi America, Ltd.
Toll Free: 1.800.HITACHI
•
Email: dmd.info@hal.hitachi.com
Web: hitachi-america.us/projectors
HI0260-Rev.1-04/14
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2014 Hitachi America, Ltd. All Rights Reserved
.
