:KHQWKHLQWHULRUSRUWLRQKDVEHFRPHRYHUKHDWHGIRUVDIHW\SXUSRVHV
WKHSURMHFWRULVDXWRPDWLFDOO\VKXWGRZQDQGWKHLQGLFDWRUODPSVPD\DOVREH
WXUQHGRII,QVXFKDFDVHGLVFRQQHFWWKHSRZHUFRUGDQGZDLWDWOHDVWPLQXWHV
$IWHUWKHSURMHFWRUKDVVXI¿FLHQWO\FRROHGGRZQSOHDVHPDNHFRQ¿UPDWLRQRIWKH
DWWDFKPHQWVWDWHRIWKHODPSDQGODPSFRYHUDQGWKHQWXUQWKHSRZHURQDJDLQ
NOTE
POWER
indicator
LAMP
indicator
TEMP
indicator
Description
/LJKWLQJ
,Q
Orange
/LJKWLQJ
,Q
Red
/LJKWLQJ
,Q
Red
Loading the saved data of CLONING on STANDBY
MODE.
Blinking
In
Orange
Blinking
In
Red
Blinking
In
Red
Loading the saved data of CLONING has failed on
STANDBY MODE.
3OHDVHUHIHUWR&/21,1* (

79 ~ 82).
7XUQHG
off
7XUQHG
off
7XUQHG
off
Loading the saved data of CLONING has
succeeded on STANDBY MODE.
Regarding the indicator lamps (continued)
Troubleshooting

Hitachi CP-TW3005 Specifications

General

Native aspect ratio	16:10
Vertical scan range	50 - 120 Hz
Horizontal scan range	15 - 106 kHz
Projection technology	3LCD
Supported aspect ratios	4:3, 16:9
Contrast ratio (typical)	10000:1
Screen size compatibility	60 - 100 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	± 5 °
Display number of colors	16.78 million colors
Fixed focal length	4.21 mm
Focal length range	- mm
Lamp power	250 W
Light source type	Lamp
Service life of light source	4000 h
RMS rated power	16 W
Supported video modes	480i, 480p, 576i, 720p, 1080i, 1080p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+)
Ethernet LAN (RJ-45) ports	1
Product type	Ultra short throw projector
