Hitachi CP-X417 Technical Manual

18
Names Operation Type Header
Command Data
CRC Action Type Setting Code
FRAME LOCK –
COMPUTER1
Set TURN OFF BE EF 03 06 00 3B C2 01 00 50 30 00 00
TURN ON BE EF
03 06 00 AB C3 01 00 50 30 01 00
Get BE EF 03 06 00 08 C2 02 00 50 30 00 00
FRAME LOCK –
COMPUTER2
Set TURN OFF BE EF 03 06 00 0B C3 01 00 54 30 00 00
TURN ON BE EF
03 06 00 9B C2 01 00 54 30 01 00
Get BE EF 03 06 00 38 C3 02 00 54 30 00 00
FRAME LOCK -
HDMI
Set TURN OFF BE EF 03 06 00 7F C2 01 00 53 30 00 00
TURN ON BE EF
03 06 00 EF C3 01 00 53 30 01 00
Get BE EF 03 06 00 4C C2 02 00 53 30 00 00
COMPUTER IN1
Set SYNC ON G ON BE EF 03 06 00 CE D6 01 00 10 20 03 00
SYNC ON G OFF BE EF
03 06 00 5E D7 01 00 10 20 02 00
Get BE EF 03 06 00 0D D6 02 00 10 20 00 00
COMPUTER IN2
Set SYNC ON G ON BE EF 03 06 00 32 D7 01 00 11 20 03 00
SYNC ON G OFF BE EF
03 06 00 A2 D6 01 00 11 20 02 00
Get BE EF 03 06 00 F1 D7 02 00 11 20 00 00
KEYSTONE V
Get BE EF 03 06 00 B9 D3 02 00 07 20 00 00
Increment BE EF 03 06 00 DF D3 04 00 07 20 00 00
Decrement BE EF 03 06 00 0E D2 05 00 07 20 00 00
KEYSTONE V Reset
Execute BE EF 03 06 00 08 D0 06 00 0C 70 00 00
KEYSTONE H
Get BE EF 03 06 00 E9 D0 02 00 0B 20 00 00
Increment BE EF 03 06 00 8F D0 04 00 0B 20 00 00
Decrement BE EF 03 06 00 5E D1 05 00 0B 20 00 00
KEYSTONE H Reset
Execute BE EF 03 06 00 98 D8 06 00 20 70 00 00
AUTO KEYSTONE
EXECUTE
Execute BE EF 03 06 00 E5 D1 06 00 0D 20 00 00
WHISPER Set NORMAL BE EF 03 06 00 3B 23 01 00 00 33 00 00
WHISPER BE EF 03 06 00 AB 22 01 00 00 33 01 00
Get BE EF 03 06 00 08 23 02 00 00 33 00 00
MIRROR Set NORMAL BE EF 03 06 00 C7 D2 01 00 01 30 00 00
H:INVERT BE EF 03 06 00 57 D3 01 00 01 30 01 00
V:INVERT BE EF 03 06 00 A7 D3 01 00 01 30 02 00
H&V:INVERT BE EF 03 06 00 37 D2 01 00 01 30 03 00
Get BE EF 03 06 00 F4 D2 02 00 01 30 00 00
VOLUME-
COMPUTER1
Get BE EF 03 06 00 CD CC 02 00 60 20 00 00
Increment BE EF 03 06 00 AB CC 04 00 60 20 00 00
Decrement BE EF 03 06 00 7A CD 05 00 60 20 00 00
VOLUME-
COMPUTER2
Get BE EF 03 06 00 FD CD 02 00 64 20 00 00
Increment BE EF 03 06 00 9B CD 04 00 64 20 00 00
Decrement BE EF 03 06 00 4A CC 05 00 64 20 00 00
VOLUME - HDMI Get BE EF 03 06 00 89 CC 02 00 63 20 00 00
Increment BE EF 03 06 00 EF CC 04 00 63 20 00 00
Decrement BE EF 03 06 00 3E CD 05 00 63 20 00 00
VOLUME-
COMPONENT
Get BE EF 03 06 00 01 CC 02 00 65 20 00 00
Increment BE EF 03 06 00 67 CC 04 00 65 20 00 00
Decrement BE EF 03 06 00 B6 CD 05 00 65 20 00 00
VOLUME-S-Video Get BE EF 03 06 00 75 CD 02 00 62 20 00 00
Increment BE EF 03 06 00 13 CD 04 00 62 20 00 00
Decrement BE EF 03 06 00 C2 CC 05 00 62 20 00 00
(continued on next page)
RS-232C communication / Network command table (continued)
RS-232C communication / Network command table (continued)
