Hitachi CP-X417 Technical Manual

21
Names Operation Type Header
Command Data
CRC Action Type Setting Code
MyScreen LOCK Set TURN OFF BE EF 03 06 00 3B EF 01 00 C0 30 00 00
TURN ON BE EF
03 06 00 AB EE 01 00 C0 30 01 00
Get BE EF 03 06 00 08 EF 02 00 C0 30 00 00
MESSAGE Set TURN OFF BE EF 03 06 00 8F D6 01 00 17 30 00 00
TURN ON BE EF
03 06 00 1F D7 01 00 17 30 01 00
Get BE EF 03 06 00 BC D6 02 00 17 30 00 00
AUTO SEARCH
Set TURN OFF BE EF 03 06 00 B6 D6 01 00 16 20 00 00
TURN ON BE EF
03 06 00 26 D7 01 00 16 20 01 00
Get BE EF 03 06 00 85 D6 02 00 16 20 00 00
AUTO KEYSTONE Set TURN OFF BE EF 03 06 00 EA D1 01 00 0F 20 00 00
TURN ON BE EF
03 06 00 7A D0 01 00 0F 20 01 00
Get BE EF 03 06 00 D9 D1 02 00 0F 20 00 00
AUTO ON
Set TURN OFF BE EF 03 06 00 3B 89 01 00 20 31 00 00
TURN ON BE EF
03 06 00 AB 88 01 00 20 31 01 00
Get BE EF 03 06 00 08 89 02 00 20 31 00 00
AUTO OFF
Get BE EF 03 06 00 08 86 02 00 10 31 00 00
Increment BE EF 03 06 00 6E 86 04 00 10 31 00 00
Decrement BE EF 03 06 00 BF 87 05 00 10 31 00 00
LAMP TIME
Get BE EF 03 06 00 C2 FF 02 00 90 10 00 00
LAMP TIME Reset
Execute BE EF 03 06 00 58 DC 06 00 30 70 00 00
FILTER TIME
Get BE EF 03 06 00 C2 F0 02 00 A0 10 00 00
FILER TIME Reset
Execute BE EF 03 06 00 98 C6 06 00 40 70 00 00
MY BUTTON-1
COMPUTER1 BE EF 03 06 00 3A 33 01 00 00 36 00 00
COMPUTER2 BE EF 03 06 00 FA 31 01 00 00 36 04 00
HDMI BE EF 03 06 00 CA 33 01 00 00 36 03 00
COMPONENT BE EF 03 06 00 6A 30 01 00 00 36 05 00
S-VIDEO BE EF 03 06 00 5A 32 01 00 00 36 02 00
VIDEO BE EF 03 06 00 AA 32 01 00 00 36 01 00
MIU BE EF 03 06 00 9A 30 01 00 00 36 06 00
INFORMATION BE EF 03 06 00 FA 3E 01 00 00 36 10 00
AUTO KEYSTONE V BE EF
03 06 00 6A 3F 01 00 00 36 11 00
MY MEMORY BE EF
03 06 00 9A 3F 01 00 00 36 12 00
PICTURE MODE BE EF
03 06 00 0A 3E 01 00 00 36 13 00
FILTER RESET BE EF
03 06 00 3A 3C 01 00 00 36 14 00
e-SHOT BE EF
03 06 00 5A 3D 01 00 00 36 16 00
VOLUME + BE EF
03 06 00 CA 3C 01 00 00 36 17 00
VOLUME - BE EF
03 06 00 3A 39 01 00 00 36 18 00
LIVE MODE BE EF
03 06 00 FA 2A 01 00 00 36 20 00
THUMBNAIL BE EF 03 06 00 6A 2B 01 00 00 36 21 00
SLIDE SHOW BE EF
03 06 00 9A 2B 01 00 00 36 22 00
DIRECTORY BE EF 03 06 00 0A 2A 01 00 00 36 23 00
REMOVE MEDIA BE EF
03 06 00 3A 28 01 00 00 36 24 00
Get BE EF 03 06 00 09 33 02 00 00 36 00 00
RS-232C communication / Network command table (continued)
RS-232C communication / Network command table (continued)
(continued on next page)
