Hitachi CP-X417 Technical Manual

22
Names Operation Type Header
Command Data
CRC Action Type Setting Code
MY BUTTON-2 COMPUTER1 BE EF 03 06 00 C6 32 01 00 01 36 00 00
COMPUTER2 BE EF 03 06 00 06 30 01 00 01 36 04 00
HDMI BE EF 03 06 00 36 32 01 00 01 36 03 00
COMPONENT BE EF 03 06 00 96 31 01 00 01 36 05 00
S-VIDEO BE EF 03 06 00 A6 33 01 00 01 36 02 00
VIDEO BE EF 03 06 00 56 33 01 00 01 36 01 00
MIU BE EF 03 06 00 66 31 01 00 01 36 06 00
INFORMATION BE EF 03 06 00 06 3F 01 00 01 36 10 00
AUTO KEYSTONE V BE EF
03 06 00 96 3E 01 00 01 36 11 00
MY MEMORY BE EF
03 06 00 66 3E 01 00 01 36 12 00
PICTURE MODE BE EF
03 06 00 F6 3F 01 00 01 36 13 00
FILTER RESET BE EF
03 06 00 C6 3D 01 00 01 36 14 00
e-SHOT BE EF
03 06 00 A6 3C 01 00 01 36 16 00
VOLUME + BE EF
03 06 00 36 3D 01 00 01 36 17 00
VOLUME - BE EF
03 06 00 C6 38 01 00 01 36 18 00
LIVE MODE BE EF
03 06 00 06 2B 01 00 01 36 20 00
THUMBNAIL BE EF 03 06 00 96 2A 01 00 01 36 21 00
SLIDE SHOW BE EF
03 06 00 66 2A 01 00 01 36 22 00
DIRECTORY BE EF 03 06 00 F6 2B 01 00 01 36 23 00
REMOVE MEDIA BE EF
03 06 00 C6 29 01 00 01 36 24 00
Get BE EF 03 06 00 F5 32 02 00 01 36 00 00
MAGNIFY Get BE EF 03 06 00 7C D2 02 00 07 30 00 00
Increment BE EF 03 06 00 1A D2 04 00 07 30 00 00
Decrement BE EF 03 06 00 CB D3 05 00 07 30 00 00
FREEZE Set NORMAL BE EF 03 06 00 83 D2 01 00 02 30 00 00
FREEZE BE EF 03 06 00 13 D3 01 00 02 30 01 00
Get BE EF 03 06 00 B0 D2 02 00 02 30 00 00
e-SHOT
Set OFF BE EF
03 06 00 3A C3 01 00 00 35 00 00
IMAGE1 BE EF 03 06 00 AA C2 01 00 00 35 01 00
IMAGE2 BE EF 03 06 00 5A C2 01 00 00 35 02 00
IMAGE3 BE EF 03 06 00 CA C3 01 00 00 35 03 00
IMAGE4 BE EF 03 06 00 FA C1 01 00 00 35 04 00
Get BE EF 03 06 00 09 C3 02 00 00 35 00 00
e-SHOT IMAGE1 Delete
Execute BE EF 03 06 00 71 C3 06 00 01 35 00 00
e-SHOT IMAGE2 Delete
Execute BE EF 03 06 00 35 C3 06 00 02 35 00 00
e-SHOT IMAGE3 Delete
Execute BE EF 03 06 00 C9 C2 06 00 03 35 00 00
e-SHOT IMAGE4 Delete
Execute BE EF 03 06 00 BD C3 06 00 04 35 00 00
CLOSED CAPTION
DISPLAY
Set
TURN OFF
BE EF 03 06 00
FA 62
01 00
00 37
00 00
TURN ON
BE EF 03 06 00
6A 63
01 00
00 37
01 00
AUTO
BE EF 03 06 00
9A 63
01 00
00 37 02 00
Get
BE EF
03 06 00
C9 62
02 00
00 37 00 00
CLOSED CAPTION
MODE
Set
CAPTIONS
BE EF 03 06 00
06 63
01 00
01 37 00 00
TEXT
BE EF 03 06 00
96 62
01 00
01 37 01 00
Get
BE EF
03 06 00
35 63
02 00
01 37 00 00
CLOSED CAPTION
CHANNEL
Set
1
BE EF 03 06 00
D2 62
01 00
02 37 01 00
2
BE EF 03 06 00
22 62
01 00
02 37 02 00
3
BE EF 03 06 00
B2 63
01 00
02 37 03 00
4
BE EF 03 06 00
82 61
01 00
02 37 04 00
Get
BE EF
03 06 00
71 63
02 00
02 37 00 00
RS-232C communication / Network command table (continued)
RS-232C communication / Network command table (continued)
