Hitachi CP-X430 - Technical Information; Dimension Diagram; Signal Connector Pin Assignment

Pin No Signal Pin No Signal Pin No Signal
1 Video input Red 9 -
15
RGB IN 1: SCL(DDC)
2 Video input Green 10 Ground RGB IN 2: -
3 Video input Blue 11 - RGB OUT: -
4 -
12
RGB IN 1: SDA(DDC)
5 Ground RGB IN 2: -
6 Ground Red RGB OUT: -
7 Ground Green 13 H. sync./ Composite sync.
8 Ground Blue 14 Vertical sync
TECHNICAL - 1
TECHNICAL
TECHNICAL
TECHNICAL
Dimension Diagram
AUDIO
IN
AUDIO
IN
CR/PR
COMPONENTVIDEO
RGBIN
RGBOUT CONTROL
12
DVI
CB/PB Y
R
AUDIOOUT USB1 2
L VIDEOIN
S-VIDEOIN
108.4
360
266
112.5
49.7
62.8
256.5
Unit : mm
3. Mini Din 4-pin Connector (S-VIDEO)
Pin No Signal
1
Color:0.286Vp-p (NTSC, burst signal),75Ω terminator
0.300Vp-p (PAL/SECAM, burst signal),75Ω terminator
2 Brightness:1.0Vp-p, 75Ω terminator
3 Ground
4 Ground
Signal Connector Pin Assignment
1. D-sub 15-pin Shrink Connector (RGB IN 1/RGB IN 2/RGB OUT)
1
23
4
5
6
7
89
10
11
1213
1415
Pin No Signal Pin No Signal Pin No Signal
1 T.M.D.S. Data 2 - 11 T.M.D.S. Data 1 / 3 Shield 21 -
2 T.M.D.S. Data 2 + 12 - 22 T.M.D.S. Clock Shield
3 T.M.D.S. Data 2 / 4 Shield 13 - 23 T.M.D.S. Clock +
4 - 14 +5V Power 24 T.M.D.S. Clock -
5 - 15 Ground (+5V, Analog H/V Sync.)
6 DDC Clock 16 Hot-Plug Sense
7 DDC Data 17 T.M.D.S. Data 0 -
8 Analog V. Sync. 18 T.M.D.S. Data 0 +
9 T.M.D.S. Data 1 - 19 T.M.D.S. Data 0 / 5 Shield
10 T.M.D.S. Data 1 + 20 -
2. Digital Receptacle Connector (DVI) (*CP-X430 only)
1234 5678
9 101112131415
16
17 18 19 20 21 22 23 24
