TECHNICAL - 2
TT
TT
EE
EE
CC
CC
HH
HH
NN
NN
II
II
CC
CC
AA
AA
LL
LL
((
((
cc
cc
oo
oo
nn
nn
tt
tt
ii
ii
nn
nn
uu
uu
ee
ee
dd
dd
))
))
Example of computer signal
• Some computers may have multiple display screen modes. Use of some of these modes
will not be possible with this projector.
• Be sure to check jack type, signal level, timing and resolution before connecting this projector to a
computer.
• Depending on the input signal, full-size display may not be possible in some cases. Refer to the
number of display pixels above.
• The image may not be displayed correctly when the input sync. signal is "Composite Sync." or
"Sync. on G".
• The image might be something wrong with computer by computer on the DVI mode. In the case, it
is recommended to reduce the resolution and / or reflesh rate.(CP-X430 only)
NOTE
Resolution
H
××
V
fH (kHz) fV (Hz) Rating Signal mode
Display mode
CP-S420 CP-X430
640 × 350
37.9 85.1 VESA VGA-1 Zoom in Zoom in
640 × 400
37.9 85.1 VESA VGA-2 Zoom in Zoom in
720 × 400
37.9 85.0 VESA TEXT Zoom in Zoom in
640 × 480
31.5 59.9 VESA VGA (60Hz) Zoom in Zoom in
640 × 480
35.0 66.7 Mac13"mode Zoom in Zoom in
640 × 480
37.9 72.8 VESA VGA (72Hz) Zoom in Zoom in
640 × 480
37.5 75.0 VESA VGA (75Hz) Zoom in Zoom in
640 × 480
43.3 85.0 VESA VGA (85Hz) Zoom in Zoom in
800 × 600
35.2 56.3 VESA SVGA (56Hz) Zoom in
800 × 600
37.9 60.3 VESA SVGA (60Hz) Zoom in
800 × 600
48.1 72.2 VESA SVGA (72Hz) Zoom in
800 × 600
46.9 75.0 VESA SVGA (75Hz) Zoom in
800 × 600
53.7 85.1 VESA SVGA (85Hz) Zoom in
832 × 624
49.7 74.5 Mac16"mode Zoom out
1024 × 768
48.4 60.0 VESA XGA (60Hz) Zoom out
1024 × 768
56.5 70.1 VESA XGA (70Hz) Zoom out
1024 × 768
60.0 75.0 VESA XGA (75Hz) Zoom out
1024 × 768
68.7 85.0 VESA XGA (85Hz) Zoom out
1152 × 864
67.5 75.0 VESA SXGA (75Hz) Zoom out Zoom out
1280 × 960
60.0 60.0 VESA SXGA (60Hz) Zoom out Zoom out
1280 × 1024
64.0 60.0 VESA SXGA (60Hz) Zoom out Zoom out
1280 × 1024
80.0 75.0 VESA SXGA (75Hz) Zoom out Zoom out
09CP-S420/CP-X43003.9.92:13PM ページ2
