Hitachi CS 33EB User Manual

Item
No.
Part Name Q’TY
1 CHAIN BAR CLAMP NUT 2
2 NAME PLATE 1
3 SIDE COVER SUB 1
4 BRAKE SUPPORT 1
5 BRAKE LINK 1
6 BRAKE LINK COVER 1
7 TAPPING SCREW (W/FLANGE) D4×16 7
8 BRAKE SPRING 1
9 CLUTCH 1
10 CLUTCH HOUSING 1
11 NEEDLE BEARING (D) 1
12 CLUTCH WASHER 1
13 CRANK SHAFT COLLAR 1
14 BRAKE BAND 1
15 TAPPING SCREW D3×8 2
16 CHAIN PULLER 1
17 GUIDE PLATE 1
18 CHAIN 1
19 CHAIN BAR 1
20 CYLINDER (B) 1
21 SPARK PLUG 1
22 COVER PACKING (B) 1
23 SCAVENGING COVER (B) 1
24 HEX. SOCKET HD. BOLT M4×8 6
25 INTAKE PACKING 1
26 INTAKE 1
27 HEX. SOCKET HD. BOLT M4×10 2
28 CARBURETOR INSULATOR 1
29 INTAKE RING 1
30 PULSE GUIDE 1
31 CARBURETOR ASS’Y (B) 1
32 CLEANER SUPPORT 1
33 TAPPING SCREW (W/FLANGE) D5×20 12
34 WASHER 5 5
35 HEX. SOCKET HD. BOLT M5 2
36 SCREW 1
37 GASKET-PASSAGE 1
38 PLATE- PASSAGE 1
39 GASKET-PUMP 1
40 BODY ASS’Y-PUMP 1
41 SCREW 1
42 SPRING 1
43 LEVER-METERING 1
44 DIAPHRAGM ASS’Y-METERING 1
45 GASKET-METERING DIAPHRAGM 1
46 COVER-METERING DIAPHRAGM 1
47 SCREW 4
48 DIAPHRAGM-PUMP 1
49 SCREEN-INLET 1
50 VALVE-INLET NEEDLE 1
51 PIN-METERING LEVER 1
52 WASHER 2
53 IGNITION COIL 1
54 HEX. SOCKET HD. BOLT (W/FLANGE) M4 2
55 CORD (B) 1
56 PISTON RING 1
57 CIR CLIP 2
58 PISTON 1
59 PISTON PIN 1
60 COVER PACKING (A) 1
61 SCAVENGING COVER (A) 1
62 CRANK WORM ASS’Y 1
63 WORM 1
64 OIL SEAL 2
65 BALL BEARING 2
66 CRANK SHAFT 1
67 MAGNET ROTOR ASS’Y 1
68 RETAINING RING D4 2
69 MAGNET ROTOR 1
70 STARTER PAWL SPRING 2
71 STARTER PAWL 2
Item
No.
Part Name Q’TY
72 BOLT WASHER D8 1
73 FLYWHEEL NUT 1
74 CLIP 3
75 FUEL PIPE (A) 2
76 FUEL GROMMET (A) 2
77 PUMP FILTER BODY ASS’Y 1
78 CRANK CASE 1
79 SEAL LOCK HEX. SOCKET HD. BOLT M5 4
80 DAMPER (B) 1
81 BOLT WASHER D5 1
82 OIL FILTER 1
83 OIL FILTER BODY 1
84 DAMPER SET BOLT 4
85 DISTANCE PIECE (B) 4
86 DAMPER (A) 4
87 CHAIN CATCHER 1
88 SPIKE 1
89 CHOKE ROD RUBBER 1
90 CHOKE BUTTON 1
91 STOP SWITCH 1
92 ENGINE CASE 1
93 CORD (A) 1
94 AIR VENT VALVE (B) 1
95 AIR VENT SPONGE 1
96 TANK CAP PACKING 2
97 TANK CAP ASS’Y 2
98 NEEDLE ROLLER D3 1
121 HEX. SOCKET HD. BOLT M5×75 2
122 EXHAUST PIPE 1
123 GAUZE FIXINGPLATE 1
124 MUFFLER GAUZE 1
125 MUFFLER 1
126 MUFFLER PACKING 1
127 CLEANER COVER 1
128 CLEANER KNOB 1
129 THLOTTLE ROD 1
130 REAR HANDLE GRIP 1
131 TRIGGER LOCKOUT 1
132 THROTTLE LEVER SPRING 1
133 SPRING PIN 5×25 1
134 THROTTLE LEVER 1
135 INNER CAP 1
136 REAR HANDLE ASS’Y 1
137 FRONT HANDLE 1
138 CLEANER ELEMENT ASS’Y 1
139 SHUTTER PLATE 1
140 CYLINDER COVER 1
141 CAYTION MARK 1
142 BRAKE HANDLE 1
143 BRAKE LEVER SPRING 1
144 NEEDLE ROLLER 2
145 PUMP CASE 1
146 PUMP GEAR SPRING 1
147 PUMP GEAR 1
148 OIL PIPE 1
149 PUMP COVER 1
150 PIPE JOINT 1
151 AIR DEFLECTOR 1
152 SET SCREW 1
153 REEL 1
154 SPRING CASE 1
155 SPIRAL SPRING 1
156 ROPE STOPPER 1
157 ROPE 1
158 STARTER KNOB 1
159 STARTER CASE 1
160 RECOIL STARTER ASS’Y 1
161 SYMBOL MARK 1
162 TAPPING SCREW (W/FLANGE) D5×25 2
501 CHAIN COVER 1
502 COMBI BOX SPANNER 1
60
