CS 33EDT
DESCRIPTION REMARKS
1 668-5225 AIR CLEANER BASE 1
2 949-824 HEX. SOCKET HD. BOLT M5 X 45 (10 PCS.) 2
3 669-6826 CLEANER SPONGE (B) 1
4 668-5230 CLEANER ELEMENT A COMP. 1
5 668-5231 CLEANER ELEMENT B COMP. 1
6 669-6825 CLEANER SPONGE (A) 1
7 669-6785 CLEANER COVER 1
8 669-6786 CLEANER KNOB 1
9 305-812
TAPPING SCREW (W/FLANGE) D4 X 16 (BLACK) 13
10 669-6821 MUFFLER COVER 1
11 669-6809 CLUTCH 1
12 669-8856 CLUTCH HOUSING 1
13 668-5361 NEEDLE BEARING (D) 1
14 668-5414 CLUTCH WASHER 1
15 668-5360 CRANK SHAFT COLLAR 1
16 669-6789 OIL PUMP COVER 1
17 668-5356 NEEDLE ROLLER 2.5 X 19.8 2
18 668-5354 PUMP GEAR 1
19 668-5355 PUMP GEAR SPRING 1
20 668-5353 PUMP CASE 1
21 669-6788 PUMP ASS'Y 1 INCLUD. 17-20
22 668-5136 SEAL LOCK BOLT M5 X 15 5
23 669-8849 INTAKE PACKING 1
24 669-6794 INTAKE 1
25 669-8385 HEX. SOCKET HD. BOLT M4 X 12 2
26 668-5203 PULSE GUIDE 1
27 669-6812 ENGINE CASE COVER 1
28 669-6792 CLEANER BODY 1
30 669-6795 CARBURETOR ASS'Y 1 INCLUD. 32-47
31 669-8857 INLET SPACER 1
32 668-5210 SCREW 1
33 PUMP BODY 1
34 668-5212 PUMP GASKET 1
35 668-5213 PUMP DIAPHRAGM 1
36 668-4700 INLET SCREEN 1
37 668-5215 NEEDLE VALVE 1
38 668-5216 VALVE SPRING 1
39 668-5217 CONTROL LEVER 1
40 668-5297 IDLE ADJUST SPRING 1
41 IDLE ADJUST SCREW 1
42 668-5218 HINGE PIN SET SCREW 1
43 668-5219 HINGE PIN 1
44 668-5220 DIAPHRAGM PACKING-METERING 1
45 668-4690 METERING DIAPHRAGM 1
46 668-5222 DIAPHRAGM COVER-METERING 1
47 668-5223 SET SCREW 4
48 669-6793 IDOL SPONGE 1
49 668-5206 CHOKE LEVER 1
50 669-8699 PROTECTIVE COIL 1
51 669-8850 FUEL PIPE 2.5 X 4 X 47 1
11 - 11 - 3 -
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
ITEM
NO.
NO.
USED
CODE NO.
