CS 33EDT
DESCRIPTION REMARKS
52 668-5139 PRIMING PUMP COMP. 1
53 668-5371 AIR VENT SPONGE 1
54 668-5370 AIR VENT VALVE (B) 1
55 669-6811 OIL PIPE 1
56 668-5358 PIPE JOINT 1
57 669-8456 FLANGED TAPPING SCREW D5 X 15 1
58 668-5363 CHAIN CATCHER 1
59 669-6807 ENGINE CASE ASS'Y 1 INCLUD. 54, 90
60 935-196
MACHINE SCREW (W/WASHERS) M4 X 12 (BLACK) 3
61 669-6816 EXHAUST PIPE 1
62 669-6818 MUFFLER SPECIAL PACKING 1
63 669-6817 GAUZE FIXING PLATE 1
64 669-6815 MUFFLER GAUZE 1
65 669-6814 MUFFLER 1
66 669-6820 MUFFLER PACKING 1
67 949-812 HEX. SOCKET HD. BOLT M4 X 10 (10 PCS.) 6
68 669-6766 SCAVENGING COVER (B) 1
70 669-6819 HEX. SOCKET HD. BOLT M6 X 55 2
71 949-432 BOLT WASHER M6 (10 PCS.) 6
72 669-8853 CRANK WORM ASS'Y 1 INCLUD. 73-76
73 668-5330 WORM 1
74 668-5329 OIL SEAL 2
75 668-5328 BALL BEARING 2
76 669-6762 CRANK SHAFT 1
77 669-6767 CRANK CASE 1
78 669-8386
HEX. SOCKET HD. BOLT (W/SP. WASHER) M5 X 18 4
79 668-5326 CIRCLIP 2
80 669-8806 PISTON (M) 1
81 668-5331 PISTON RING (XR1-1856) 1
82 669-6764 PISTON PIN 1
83 668-5103 BOLT WASHER M7 1
84 668-5104 FLYWHEEL NUT 1
85 668-5336 RETAINING RING D4 2
86 669-7026 MAGNETO ROTOR COMP. 1
87 668-5335 STARTER PAWL SPRING 2
88 668-5334 STARTER PAWL 2
89 668-5102 MAGNETO ROTOR ASS'Y 1 INCLUD. 85-88
90 668-5351 INNER CAP 1
91 668-5179 TANK CAP PACKING 2
92 669-8854 FUEL TANK CAP ASS'Y (VERMILION) 2 INCLUD. 91
93 669-6761 CYLINDER 1
94 668-5782 SPARK PLUG BPMR7A 1
95 669-8867 IGNITION COIL 1
96 669-8700 GLASS WASHER 2
98 669-6765 SCAVENGING COVER (A) 1
99 669-6772 METAL FITTING OF PLUG CAP (A) 1
100 669-6787 CORD (A) 1
101 669-6771 SPARK PLUG CAP 1
102 669-6791 CORD (B) 1
103 669-8388
HEX. SOCKET HD. BOLT (W/WASHERS) M4 X 18 2
- 4 - 11 - 11
*ALTERNATIVE PARTS
NO.
USED
CODE NO.
ITEM
NO.
CODE NO.
ITEM
NO.
