Hitachi CS 33EDT Service Manual

PART
S
CS 33EDT
DESCRIPTION REMARKS
104 668-5226 WASHER M5 (BLACK) 2
105 669-8864 CAUTION LABEL (HOT) 2
106 669-8787 GROMMET 3
107 669-8860 PROTECTION SHEET 2
108 669-8861 PACKING PLATE 1
109 669-8862 MUFFLER SPECIAL PACKING (S) 1
110 668-4899 WOODRUFF KEY 3 X 13 X 4.5 1
111 669-8863 CORD INSULATION TUBE 2
121 316-458 TAPPING SCREW D5 X 40 (BLACK) 1
122 669-8858 WASHER 1.0 1
123 669-6800 COLLAR 28.2 1
124 669-6775 DAMPER 1
125 669-6774 REAR HANDLE (B) 1
126 668-5244 TRIGGER LOCKOUT 1
127 669-6797 THROTTLE WIRE 1
128 669-6940 STOP SWITCH 1
129 669-8449 NUT M6 2
130 669-8691 THROTTLE LEVER SPRING 1
131 668-5242 THROTTLE LEVER 1
132 669-8409 SPRING HOLDER 2
133 669-8859 DAMPER SET BOLT 2
134 669-8428 ANTIVIBRATION SPRING 2
135 NAME PLATE 1
136 669-8581 FLANGE NUT M8 1
137 669-6776 SIDE CASE (VERMILION) 1
138 669-6782 BRAKE SUPPORT PLATE 1
139 669-6783 BRAKE LEVER SPRING 1
140 668-5388 BRAKE LINK 1
141 668-5140 BRAKE BAND 1
142 668-5391 NEEDLE ROLLER D3 1
143 668-5389 BRAKE SPRING 1
144 668-5393 CHAIN PULLER 1
145 669-6784 GUIDE PLATE (B) 1
146 696-352 TAPPING SCREW D3 1
147 958-715 TAPPING SCREW D4 X 10 1
* 148 668-5170 SAW CHAIN (3/8 X 12") 91VG-45E 1
* 148 668-5171 SAW CHAIN (3/8 X 14") 91VG-52E 1
* 149 669-6990 CHAIN BAR 12 INCH 3/8 SPROCKET PRC 1
* 149 669-6991 CHAIN BAR 14 INCH 3/8 SPROCKET PRC 1
150 669-8715 FUEL PIPE 1
* 151 669-6827 SPIKE SET 1 FOR EUROPE, RUS, AUS, NZL, CHN
152 669-8851 FUEL PIPE (FKM) L240 1
154 669-8852 FUEL PIPE (FKM) L260 1
155 669-6167 FUEL GROMMET 1
156 669-6773 REAR HANDLE (A) 1
157 303-273 TAPPING SCREW (W/FLANGE) D5 X 16 2
158 669-6798 FRONT HANDLE 1
159 669-8866 BRAKE HANDLE 1
* 160 CAUTION LABEL (B) 1
* 160 CAUTION LABEL (C) 1 FOR EUROPE
11 - 11 - 5 -
*ALTERNATIVE PARTS
NO.
USED
CODE NO.
ITEM
NO.
