INSTALLATION
PMML0503 rev.0 - 05/20193
ENGLISH
3 INSTALLATION
C A U T I O N
Disregarding the safety and assembly instructions
may result in the falling of and / or damage to
your electrical appliance. Opening the package
represents your undertaking to closely read and
follow the instructions. This device is not intended
for use in public places.
Local or national regulations must be followed at
all times during the preliminary work to prepare
the electric power line for the equipment.
N O T E
For further information consult the current regulations in the country where
the unit is to be installed.
3.1 CONNECTORS DESCRIPTION
o
p r s t u
v
w
x
y
q
No. Description
1 Power supply
2 RJ45 Ethernet
3 USB for log
4 Push button
5 RS485 for Modbus RTU
6 '6:IRUGHYLFHFRQ¿JXUDWLRQ
7 H-LINK comunication
8 Inputs
9 Ouputs
10 LEDs for operation indication
11 86%DWFRQ¿JXUDWLRQWLPHRQO\
