English
9
Drilling holes in concrete or tile
SDS-plus Drill bit
Outer dia. Overall length Effective length
4.0 mm 110 mm 50 mm
5.0 mm
110 mm 50 mm
160 mm 100 mm
5.5 mm 110 mm 50 mm
6.5 mm 160 mm 100 mm
7.0 mm 160 mm 100 mm
8.0 mm 160 mm 100 mm
8.5 mm 160 mm 100 mm
9.0 mm 160 mm 100 mm
12.0 mm
166 mm 100 mm
260 mm 200 mm
12.7 mm 166 mm 100 mm
14.0 mm 166 mm 100 mm
15.0 mm 166 mm 100 mm
16.0 mm
166 mm 100 mm
260 mm 200 mm
17.0 mm 166 mm 100 mm
19.0 mm 260 mm 200 mm
20.0 mm 250 mm 200 mm
22.0 mm 250 mm 200 mm
25.0 mm 450 mm 400 mm
30.0 mm 450 mm 400 mm
Drill bit (slender shaft)
Outer dia. Overall length Effective length
3.4 mm
90 mm 45 mm
3.5 mm
Taper shank adapter
Taper mode
Morse taper No.1
Morse taper No.2
A-Taper
B-taper
Drilling anchor holes
Core bit
Center pin
Core bit shank
Outer dia. Overall length
25 mm*
Not applicable
29 mm*
32 mm
105 mm
35 mm (A)
300 mm
38 mm
45 mm
(B) 300 mm
50 mm
Large hole boring
Anchor setting adapter
Anchor size
W 1/4”
W 5/16”
W 3/8”
W 1/2”
W 5/8”
Anchor setting
Optional accessories are subject to change without notice.
* Without guide plate
01Eng_DH24PB3_WE 6/26/08, 20:499
