45
ITEM
NO.
PART NAME Q’TY
1 FRONT CAP 1
2 GRIP 1
3 STOPPER RING 1
4 NEEDLE HOLDER 1
5 RETAINER SPRING 1
6 SPRING HOLDER (A) 1
7 CYLINDER CASE 1
8 HEX. SOCKET HD. BOLT (W/FLANGE) M6×25 4
9 O-RING (1AS-60) 1
10 RETAINER DAMPER 1
11 RETAINER DAMPER WASHER 1
12 RETAINER SLEEVE 1
13 NEEDLE ROLLER D8×20 2
14 O-RING (C) 1
15 SECOND HAMMER 1
16 DAMPER WASHER 1
17 DAMPER 1
18 DAMPER HOLDER 1
19 CYLINDER 1
20 SPRING HOLDER (B) 1
21 LOCK SPRING 1
22 LOCK SLEEVE 1
23 CLUTCH SPRING 1
24 CLUTCH 1
25 BEVEL GEAR 1
26 THRUST WASHER 1
27 STRIKER 1
28 O-RING 2
29 PISTON PIN 1
30 PISTON 1
31 CONNECTING ROD 1
32 SEAL LOCK HEX. SOCKET HD. BOLT M4×12 1
33 CHANGE LEVER 1
34 LEVER HOLDER 1
35 RETAINING RING FOR D20 HOLE 1
36 LEVER SHAFT 1
37 O-RING (P-16) 1
38 PIN D2×10 1
39 LEVER SPRING 1
40 PUSHING BUTTON 1
41 BALL BEARING 6201DDCMPS2L 1
42 DUST WASHER (B) 1
43 ARMATURE 1
44 FAN GUIDE 1
45 HEX. HD. TAPPING SCREW D5×55 2
46 STATOR ASS'Y 1
47 BRUSH TERMINAL 2
48 HOUSING ASS'Y 1
49 SLIP CLUTCH ASS'Y 1
50 BEVEL PINION 1
51 FEATHER KEY 3×3×82
52 COLLAR 1
53 OIL SEAL (A) 1
54 BALL BEARING 6002DDCMPS2L 1
55 WASHER 1
56 WASHER (A) 1
57 GEAR HOLDER 1
58 SPRING (C) 10
59 NEEDLE 10
60 SECOND GEAR 1
61 SPACER 1
62 BALL BEARING 629VVC2PS2L 1
63 BEARING WASHER (C) 1
64 SEAL LOCK HEX. HD. BOLT M6×20 2
65 SEAL LOCK HEX. SOCKET HD. BOLT M6×45 4
66 HITACHI LABEL 1
67 SEAL LOCK HEX. SOCKET HD. BOLT M5×16 6
68 CRANK COVER 1
69 CYLINDER O-RING (B) 1
70 CRANK CASE 1
ITEM
NO.
PART NAME Q’TY
71 SEAL PACKING 1
72 RETAINING RING FOR D10 SHAFT 1
73 CRANK SHAFT 1
74 RETAINING RING FOR D40 HOLE 1
75 BALL BEARING 6203DDCMPS2L 1
76 O-RING (S-40) 1
77 OIL SEAL (B) 1
78 FIRST GEAR 1
79 NEEDLE BEARING (M661) 1
80 GEAR COVER 1
81 WING BOLT M6×12 1
82 MOUNT 1
83 NUT M6 1
84 HANDLE BOLT 1
85 BAND 1
86 SIDE HANDLE 1
87 BRUSH CAP 2
88 CARBON BRUSH 2
89 BRUSH HOLDER 2
90 HEX. SOCKET SET SCREW M5×82
91 WASHER (A) 1
92 BALL BEARING 608VVC2PS2L 1
93 BEARING HOLDER 1
94 TAIL COVER 1
95 TAPPING SCREW (W/FLANGE) D5×20 4
97 HANDLE 1
100 NAME PLATE 1
101 CORD 1
102 CORD ARMOR 1
104 SWITCH (C) 1
105 PILLAR TERMINAL 1
107 CORD CLIP 1
108 TAPPING SCREW (W/FLANGE) D4×16 2
109 HANDLE COVER 1
110 TAPPING SCREW (W/FLANGE) D4×25 (BLACK) 2
501 CASE 1
