K6602705
Rev.3
08.20.01
- 74 -
6.3.2.9.5 Security Set Password [F1h]
This command requests a transfer of a single sector of data from the host. The following table defines the
content of this sector of information. The data transferred controls the function of this command.
The revision code field is returned in the Identify Device word 92. The valid revision codes are 0000h
to FFFDh. The initial factory shipped value of Master Password Revision code shall be FFFEh. Value
FFFFh is revised.
Word Contents
0 Control Word
Bit 15-9Reserved
Bit 8 Security Level 0 = High
1 = Maximum
Bit 7 Reserved
Bit 0 Identifier 0 = Set user password
1 = Set master password
1-16 Password(32bytes)
17 Mater Password Revision Code (Valid if word 0 bit 0 = 1)
18 - 255 Reserved
The following table defines the interaction of the identifier and security level bits.
Identifier Security
Level
Command Result
User High The password supplied with the command shall be saved as the new
user password. The lock function shall be enabled from the next
power-on or hardware reset. Either the user password or the
previously set master password shall then unlock the device.
User Maximum The password supplied with the command shall be saved as the new
user password. The lock function shall be enabled from the next
power-on or hardware reset. The device shall then be unlocked by only
the user password. The master password previously set is still stored
in the device but shall not be used to unlock the device.
Master High or
Maximum
This combination shall set a master password but shall not enable or
disable the lock function. The security level is not changed. Master
password revision code set to the value in Master Password Revision
Code field.
Device returns Aborted command error if the device is in Locked mode or Frozen mode.
