English
11
Input power source Single phase: AC 120 V 60 Hz
Charging time
Approx. 45 min.
(At a temperature of 68°F (20°C))
Charging voltage DC 14.4 V 18 V
Charger
Charging current DC 3.5 A
Weight 1.3 lbs. (0.6 kg)
NOTE: The charging time may vary according to temperature and power source voltage.
3. Battery Charger (UC18YRSL)
Model DV14DSL DV18DSL
Motor DC motor
No-load speed Low 0–400/min
High 0–1,400/min
Capacity Drilling Brick (Depth
1/2"(13 mm)
1-1/4" (30 mm))
Wood (Thickness
1-27/64" (36 mm)
11/16" (18 mm))
Metal (Thickness
1/2" (13 mm)
1/16" (1.6 mm))
Screw Wood screw #16 × 2" #20 × 3"
Driver (6.8 mm × 50 mm) (8 mm × 75 mm)
Small screw 1/4" (6 mm)
Drill chuck capacity Maximum gripping diameter 1/2" (13 mm)
Battery Model BSL1430 BSL1830
Type Li-ion battery
Voltage DC 14.4 V DC 18 V
Weight 3.7 lbs. (1.7 kg) 3.9 lbs. (1.8 kg)
2. Cordless Hammer Drill
01Eng_DS14DSL_US 4/22/08, 10:2011
