2
1.2 Components
Air-Cooled
Oil cooler
Intercooler
Aftercooler
Air intake filter
Oil mist remover
(OMR)
Discharge pipe
(Compressed air discharge)
Oil level gauge
Control panel
Enclosure
Instrument panel
Main motor
Oil filter
1st-stage
Airend
2nd-stage
Airend
Check valve
Cooling fan
Common base
Air relief valve
[Front View]
[Rear View]
