CP-A100 / ED-A100 / ED-A110 (A1DN)
(2)Attaching the Lenz to the bottom bracket
Combine two
Tighten 3 screws to attach A1 LCD/LENS/PRISM ASSY to Engine base plate.
parts of lens to part of bottom bracket.
(3)Disassembling the mirror motor and focus motor
Remove 3 black screws to detach the mirror motor.
Never remove any other screws.
3 black screws
Remove 2 screws to detach the focus motor.
parts of lens
part of Engine base plate
2 screws
