8-6. Insulation Tests
On completion of disassembly and repair, measure the insulation resistance, and conduct the dielectric strength
test.
Insulation resistance: 7 M or more with DC 500V Megohm Tester
Dielectric strength test: AC 4,000 V/1 minute, with no abnormalities
••••••••••••••
220 V --- 240 V products
AC 2,500 V/1 minute, with no abnormalities
••••••••••••••
110 V --- 127 V products
8-7. No-Load Current Value
After no-load operation for 30 minutes, the no-load current value should be as follows.
Voltage (V)
Current (A) max.
110 220 230 240
3.2 1.7 1.7 1.6
