CONTROLS (See Fig. 1)
@) POWER switch
When this switch is depressed (ON) (&), the
power is supplied to the turntable. The switch
is released to turn off the power.
Always keep the power off when not using the
turntable.
(5) QUARTZ LOCKED indicator
This indicator lights to show that the quartz
lock has engaged and that the platter (1) is
rotating at the rated speed.
@ EP ADAPTOR
When
playing
an
EP
disk
(doughnut
type)
with
a
large
center
hole,
place
the
EP
ADAPTOR
provided on the spindle @).
Meee
@ SPEED select switch
This is automatically set to 33-1/3 rpm with
a 30 cm disk (LP) and to 45 rpm with a 17
cm disk (single or EP).
Depress the switch and set it to the required
speed when playing 30 cm disks at 45 rom and
17 cm or 25 cm disks at 33-1/3 rpm.
REPEAT switch
Depress this switch for repeat play and make
the repeat indicator light. This function is
automatically released when the power is swit-
ched off.
MOUNTING THE CARTRID
* Replacing the cartridge with head shell
You
can
easily
lock
and
detach
the
head
shell
by
rotating the locking screw.
(See Fig. 4)
Cartridge installation or replacement
Perform
installation
or
replacement
of
the
cartridge
as
follows:
The
polarities
and
L,
R
channel
of
the
lead
wires
of
the
head
shell
are
shown
in
the
Fig.
5.
The
connec-
tion
should
be
done
according
to
the
terminal
indica-
tion
of
the
cartridge.
Mount the cartridge onto the head shell and fasten
gently with the cartridge fixing screws. (Fig. 6)
*
@ UP/DOWN (tonearm) switch
When this switch is depressed, the tonearm (4)
rises (UP) or falls (DOWN).
Normally, it is kept to the DOWN position.
When this switch is depressed during disk play,
the tonearm rises and temporary play
suspension is possible. When depressed again,
the tonearm (4descends onto the disk and play
resumes.
af
START/CUT switch )
For automatic play, unfasten the rest hook
from the tonearm (4) and depress this switch.
The platter @ will now start to rotate, the
tonearm (4 will move across to the disk, and
automatic play will begin.
To stop play halfway across a disk (Auto-
cut)
Push the START/CUT switch@, the tonearm
(4 automatically returns to the arm rest (3).
a
:
@ Size detecting lamp
This lamp is designed to automatically check
the size of the disk on the platter. It lights when
the POWER switch @ is set to ON (QQ). The
beginning of disk play is signaled with two or
three winks.
(3) Arm rest
When you do not intend to play any disks,
secure the tonearm(4 to the arm rest.
When the tonearm(4 is disengaged from the
arm rest, the platter@ will automatically rotate.
GE
AND
ADJUSTMENTS
* Adjust the position of the cartridge for proper stylus
overhang by measuring distance from stylus to neck
and set the cartridge in parallel with the front end of
the head sheel. Fig. 7 shows the actual size, so
measure the distance by placing the head shell on
Fig. 7. ;
* Then secure the cartridge fixing screws. (Fig. 6)
e Stylus replacement
When sound becomes distorted or noisy, check the
stylus to see whether it is worn out or not. If worn
out, replace it with a new one. Refer to Fig. 9 when
replacing stylus.
