13" PLANER MODEL NO. P13F
Always order by I.D. Number.
PARTS LIST FOR SCHEMATIC A
HKU# I.D. Description Size Qty HKU# I.D. Description Size Qty HKU# I.D. Description Size Qty
726339 2111 CUSHION 2 726417 088L SIDE COVER 1 726552 0K71 CR.-RE. TRUSS HD. SCREW M5*0.8-8 4
726340 2113 SET BOLT M4X0.7-2B 2 726418 088N SIDE COVER 1 726553 0K72 CR.-RE. TRUSS HD. SCREW M5X0.8-12 4
726341 2114 BLADE 2 726419 088R COVER 1 726557 0K7K CR. RE. ROUND WASHER HD. SCREW M6*1.0-12 19
726342 2116 TENSIONH ANDLE 1 726420 088S SCALE RING 1 726560 0K84 CR. RE.COUNT HD. TAPPING SCREW M4*0.7-12 3
726343 2118 TENSION HANDLE 1 726338 0893 FOLLOWER PLATE 1 726563 0K91 CR. RE. TRUSS HD. TAPPING SCREW M4*16-12 2
726344 2125 BASE 1 726421 089Q SET PLATE 1 726573 0KB9 CR.RE. PAN HD. TAPPING SCREW M5X16-10 4
726390 086G INSERT 1 726422 089R SET PLATE 1 726584 0KE9 CR. RE. PAN HD. SCREW M6*1.0-30 2
726391 086H
CHAIN 1 726423 089S SPROCKET 1 726593 0KKL CR.RE. PAN HD. ROUND NECK SCREW
M6*1.0-16 1
726392 086K SPROCKET 2 726424 089Y ROLLING WHEEL 2 726597 0KMS HEX. NUT M6*1.0 T=5 4
726393 086L BEARING COVER 2 726425 089Z SHAFT 2 726603 0KMY HEX. NUT M8*1.25T=6.5 1
726394 086N
GUIDE PLATE 2 726426 08A0 BRACKET TRAY 4 726613 0KQM SQUARE NUT M6*1.0 T=5 8
726395 086P TABE PLATE 1 726427 08A1 MOTOR PULLEY 1 726616 0KQX NUT CHUCK M6*1.0 T=6 4
726396 086S SCREW BAR 2 726428 08A2 SPRING 1 726617 0KQY NUT CHUCK M8*1.25 T=8
2
726397 086T SUPPORT 4 726429 08A5 FOUNDATION STONE ASS'Y 2 726619 0KRJ U-TYPE NUT M4*0.7 2
726324 0870 EXTENTION WING ASS'Y 2 726430 08AK C0LLAR 1 726636 0LXZ DSICCANT 2
726325 0874 ROLLING WHEEL 2 726431 08AM
MOTOR BASE 1 726637 0LYR STEEL BALL 1
726326 0875 SHAFT SLEEVE 8 726467 0HV4 BALL BEARING 2 726658 210F MIDDLE BASE 1
726327 0876 SHAFT 2 726468 0HVM BALL BEARING 2 726659 210Y COVER 1
726328 0877 SPRING PLATE 2 726473 0J3P WRENCH HEX. 1 726660 210Z FOLLOWER PLATE 1
726329 0878 BODY 1 726477 0J4E FLAT WASHER φ6*13-1 2 726661 211C TOOL BOX COVER 1
726330 0879 NEEDLE POINTER 1 726484 0J6G FLAT WASHER φ8.2*18-2.0 1 726662 211D TOOL BOX COVER 1
726398 087A
SPRING 1 726491 0J78 FLAT WASHER 1/4*1/2-3/32 6 726663 211E BASE 4
726399 087B RIVET 1 726492 0J7B FLAT WASHER 5/16*25/32-1/8 2 726664 212S SPONGE 1
726400 087G ARM BRACKET 1 726497 0J95 SPRING WASHER φ6 2 726667 216J V-RIBBED BEIT(POIYOURETHANE) 1
726401 087H
SPACER 1 726504 0JBA WAVE WASHER BWW-6203 1 726669 21XQ CR. RE. ROUND WASHER HD. SCREW 4
726402 087K HANDLE 1 726511 0JDC
SPRING PIN 2.5-22 2 726670 221Q CUTTER HEAD 1
726403 087N
LINK BAR 2 726512 0JEC C-RING A-15 1 726671 221R PRESSURE BAR 2
726404 087Q SLEEVE 2 726514 0JEV E-RING E-6 4 726672 222E NEEDLE POINTER 1
726405 087S CHAIN 1 726518 0JGB PARALLEL KEY 5*5-15 1 726734 24ZN HANDLE 1
726406 087T CHAIN 1 726524 0JPC HEX. HD. BOLT M6*1.0-12 1 726747 26DP SPECIAL BOLT 4
726407 087U
BEARING COVER 1 726525 0JPF HEX. HD. BOLT M6*1.0-25 4 726792 28KA PLATE COVER 1
726331 0880 ADJUST SCREW 4 726529 0JQ1 HEX. HD. BOLT M10*1.5-45 4 726793 28KB COVER-RINHT 1
726332 0881 BEARING SEAT 1 726530 0JUB HEX. SOC. HD. CAP BOLT M5*0.8-12 1 726794 28KL HANDLE 2
726333 0882 PULLEY 1 726531 0JV0 HEX. SOC. HD. CAP BOLT M8*1.25-45 1 726795 28KP KNOB 1
726334 0886 TABLE INSERT 1 726536 0JXQ HEX. SOC. SET SCREW M10*1.5-12 1 726800 28M5 MOTOR ASS'Y 1
726335 0887 SPROCKET 3 726537 0JZ4 HEX. SOC. SET SCREW M6*1.0-8 2 726801 28MA
SACLE PLATE ASS'Y 1
726336 0888 SHAFT SLEEVE 1 726528 0JZN HEX WASHER HD BOLT M8*1.25-20 1 726814 28PE HANDLE BAR ASS'Y 1
726337 0889 ANCHOR BLOCK 4 726529 0JZY HEX. SOC. TRUSS HD. SCREW M6*1.0-12 2 726817 28QS POWER CORD CLAMP 2
726408 088A
COMPRESSION SPRING 4 726537 0K1D HEX. HD. SCREW AND WASHER M6*1.0-16 16 726822 28VG
TRADE-MARK LABEL 1
726409 088B FEED SHAFT 2 726539 0K2B HEX.SOCKET HD.CAP SCREWS M6*1.0-16 2 726823 28VH CAUTION LABEL 1
726410 088C
SHAFT SLEEVE 1 726541 0K30 HEX. SOCKET TRUSS HEAD & WASHER ASSEMBLIED M6*1.0-16 8 726824 28VJ WARNING LABEL 1
726411 088D
SET PLATE 4 726542 0K33 CR.RE. PAN HD. SCREW & WASHER M4*0.7-8 2 726825 28VK STICKER 2
726412 088E NUT 2 726544 0K3H CR.RE. PAN HD. SCREW & WASHER M6*1.0-12 20 726826 28VL SCALE 1
726413 088F NUT 2 726546 0K47 CR.RE. PAN HD. SCREW & WASHER M6*1.0-20 1 726827 28VM
SCALE 1
726414 088G ADJUSTABLE NUT 2 726547 0K4D CR.RE. PAN HD. SCREW & WASHER M6*1.0-12 2 726828 28VN BRACKET-TILT 1
726415 088H
MITER GUIDE 1 726550 0K5B CR. RE. COUNT HD. SCREW M6*1.0-12 14 726829 28VP SCALE 1
726416 088J DUST PORT 1 726551 0K61 CR. RE. COUNT HD. SCREW M5*0.8-12 2 726830 28VQ
