13” PLANER MODEL NO. P13F
PARTS LIST FOR STAND
HKU# I.D. Description Size Qty
726435 093B CUSHION 4
726489 0J72 FLAT WASHER 1/4*5/8-1/16 4
726526 0JPG HEX. HD. BOLT M6*1.0-30 4
0KJD CAP HD. SQ.NECK BOLT M8*1.25-16 40
726620 0KRQ SERRATED TOOTHED HEXAGON FLANGE NUT M6*1.0 T=6 4
726621 0KRR SERRATED TOOTHED HEXAGON FLANGE NUT M8*1.25 T=7.5 40
726703 238H BRACKET 843.5*85-45 T=1.5mm 4
726704 238J UPPER SUPPORT 523.4*65 T=1.5mm 2
726706 238L UPPER SUPPORT 363.5*65 T=1.5mm 2
726708 238P BOTTOM SUPPORT BRACKET 634.7*60 T=1.5mm 2
726709 238Q BOTTOM SUPPORT BRACKET 473.3*60 T=1.5mm 2
— 50 —
