Hitachi PDA-100D User Manual

2
English
中國語

1
Wrench
扳手

2
Wheel nut
砂輪螺帽

3
Depressed center wheels
砂輪

4
Wheel washer
輪墊圈

5
Spindle
主軸

6
Notched part
槽口部分

7
Wheel guard
砂輪保護裝置

8
Tighten
緊

9
Convex side
凸面

0
Lock pin
鎖定銷

!
Washer nut
墊片螺帽

@
Sanding disc
砂盤

#
Rubber pad
橡膠墊圈

$
Washer
襯墊

%
Guide base
導軌基座

^
Guide piece
導軌片

&
Set plate (A)
支架板 (A)
 (A)
*
Screwdriver
螺絲刀

*
Screw
螺絲釘

)
Diamond wheel
金剛石輪

q
Wing bolt
蝶形螺栓




w
Adjust the cutting depth by losening
the wing bolt.
利用放鬆蝶形螺栓來調節切削深度









e
Wear limit
磨損極限



r
No. of carbon brush
碳刷號

000BookPDA-100DTha.indb2000BookPDA-100DTha.indb2 2009/04/109:23:322009/04/109:23:32
