TECHNICAL SPECIFICATIONS
Power supply AC adapter : AC230V~50Hz
DC source : DC 12V / 2000mA (center positive)
Power Consumption 24W
Operation Temperature (humidity) 0 --- 40 deg C (less than 95%, no condensation)
Screen Display 7” / 16:9 TFT panel
Discs Played DVD-Video, CD-DA, CD-R/RW, MP3, JPEG, VCD 2.0
Video Formats PAL / NTSC
Audio out Analog audio out : 1.4V / 10K ohm load
Frequency Response 20Hz ~ 20KHz +/- 3dB
Video out Composite video 1.0Vp-p 75 ohm
Input Analog audio / Composite video
Battery Rechargable Ni-MH battery : 7.2V / 3800mA
Rechargable time : approx. 180mins
Playback time : approx. 150mins
Dimension Main unit : ( 233 x 165 x 44.2 ) mm
Battery pack : ( 228 x 82 x 26 ) mm
Weight (Full package) Approx. 2.25kg
