Hitachi RAC-07CHV1 User Manual

– 25 –
SIGN
R101 1.0 J 1/4
POWER
(W)
TOLERANCE
RESISTANCE
(Ω)
RATING VALUE
RESISTOR (Ω)
J ••• ±5%, G ••• ±2%, F ••• ±1%,
R102 10K G 1/10
R103 1.2K G 1/10
R104 1.0 J 1/4
R201 10K J 1/10
R202 10K J 1/10
R203 2.7K J 1/10
R204 5.1K J 1/10
R205 1M J 1/10
R206 10K J 1/10
R208 5.1K J 1/10
R209 10K J 1/10
R210 12K J 1/10
R211 12K J 1/10
R302 1K J 1/10
R303 10K J 1/10
R304 62K J 1/10
R305 27K J 1/10
R306 15K J 1/10
R307 1K J 1/10
R308 12.7K F 1/10
R309 1K J 1/10
R310 12.7K F 1/10
R311 1K J 1/10
R312 10K J 1/10
R401 390 J 1/10
R402 390 J 1/10
R403 390 J 1/10
R404 390 J 1/10
R405 5.1K J 1/10
R406 5.1K J 1/10
R407 10K J 1/10
R408 10K J 1/10
R409 10K J 1/10
R410 10K J 1/10
R601 10K J 1/10
R603 10K J 1/10
R606 10K J 1/10
R607 10K J 1/10
R608 1K J 1/10
R609 1K J 1/10
R610 1K J 1/10
R611 10K J 1/10
R702 390 J 1/10
R703 200 J 1/10
R705 1K J 1/10
R709 1K J 1/4
R710 1K J 1/4
R801 3.3K J 1/10
R802 1K J 1/10
R810 5.1K J 1/10
R811 5.1K J 1/10
TRANSISTOR
SIGN MODEL
Q201 2SC2462LC
Q202 2SA1121SC
Q903 2SA1469S
Q904 2SC3624
R812 20 J 1/4
R813 20 J 1/4
R901 20K F 1/10
R902 300 J 1/10
R903 2.21K F 1/10
R904 2K J 2
R905 2K J 2
R906 1.5 J 1/4
R909 1.5 J 1/4
R910 1.5 J 1/4
DIODE
SIGN MODEL
D101 G4DL-6140
D102 D1FS6
D201 HSM2838C
D401 HSM2838C
D403 HSM2836C
D901 D1FL20U
D902 LFB01
LED
SIGN
LD702 SLR-332DC3F ORANGE
ZENER DIODE
SIGN MODEL
ZD201 RLZ24
ZD202 RLZ10
ZD701 RD5.1UJN2
INDUCTOR
SIGN MODEL
L101 82µH, 1.3A
L102 560µH, 0.6A
L901 450µH, 1.5A
IC
SIGN MODEL
REG1 IR3M03AN
REG2 MC7805CT
IC1 HD6433714
IC401 X24C01SI
IC501 ULN2003ANS
ICP ICP-S0.5
OSCILLATOR
MODEL EF0EC8004A4
MODEL RAS-07CH1, RAS-09CH1
SIGN
C101 470µ 50 D
TYPE
VOLTAGE
(V)
CAPACITANCE
(F)
RATING VALUE
CAPACITOR
TYPE C ••• CERAMIC CAPACITOR
D ••• ELECTROLYTIC CAPACITOR
F ••• FILM CAPACITOR
C102 150µ 35 D
C103 100µ 10 D
C104 0.1µ 25 C
C105 220P 50 C
C107 0.47µ 25 C
C108 0.022µ 50 C
C201 33µ 10 D
C202 0.047µ 25 C
C205 0.1µ 25 C
C206 0.1µ 25 C
C301 0.047µ 25 C
C302 0.047µ 25 C
C303 0.047µ 25 C
C401 0.047µ 25 C
C601 0.047µ 25 C
C701 33µ 10 C
C702 1000P 50 C
C801 3300P 50 F
C802 30P 50 C
C803 0.022µ 50 C
C804 0.01µ 50 C
C805 0.22µ 50 F
C806 150P 50 C
C807 0.22µ 50 F
C901 220µ 50 D
C933 10µ 16 C
C940 10µ 16 C
C942 0.1µ 25 C
R911 1.5 J 1/4
R915 1.5 J 1/4
R920 3.3K J 1/10
R921 3.3K J 1/10
R930 1K F 1/10
R931 8.25K F 1/10
R932 5.1K J 1/10
MODEL COLOUR
LD703 SLR-332YC3F YELLOW
