Hitachi RAC-07CHV1 User Manual

– 26 –
SIGN
R100 –––
POWER
(W)
TOLERANCE
RESISTANCE
(Ω)
RATING VALUE
RESISTOR (Ω)
J ••• ±5%, G ••• ±2%, F ••• ±1%,
R201 470K J 1/4
R202 470K J 1/4
R203 100K J 2
R205 47 J 2
R206 47 J 2
R207 –––
R209 33 J 2
R210 430 J 1/4
R211 –––
R212 100 J 1/6
R213 330 J 1/6
R214 4.7K J 1/6
R215 5.76K F 1/6
R216 1.47K F 1/6
R217 1.3K J 2
R218 1.3K J 2
R219 1.3K J 2
R220 1.3K J 2
R301 3.6K J 1/6
R302 10K J 1/6
R303 –––
R304 100 J 1/6
R305 10K J 1/6
R306 4.7K J 1/6
R307 –––
R308 5.9K F 1/6
R309 10K J 1/6
R310 5.1K J 1/6
R311 100K J 1/6
R312 1K J 1/6
R313 1M J 1/6
R314 680 J 1/6
R315 10K J 1/6
R316 10K J 1/6
R317 10K J 1/6
R401 390 J 1/6
R402 390 J 1/6
R403 5.1K J 1/6
R404 5.1K J 1/6
R405 390 J 1/6
R406 390 J 1/6
R501 5.1K J 1/6
R502 20 J 1/4
R503 20 J 1/4
R504 1K J 1/6
R505 –––
R601 2K J 1/6
R602 10K J 1/6
TRANSISTOR
SIGN MODEL
Q201 2SC4300
Q202 2SC2655
Q601 2SD2019
Q701 2SC458
R701 3K J 1/6
R702 10K J 1/6
R703 5.1K J 1/6
R704 2.7K J 1/6
R705 5.1K J 1/6
R802 2.2 J 5
R803 470K J 1/2
R804 2.7K J 1/6
Q702 2SA673
DIODE
SIGN MODEL
D201 ERB4408
D202 1SS120
D203 1SS120
D204 –
D205 RMPG06G
D206 –
D207 YG902C2
D401 1SS120
D402 1SS120
D403 1SS120
D404 1SS120
D601 1SS120
LED
SIGN MODEL
LD801 RED
ZENER DIODE
SIGN MODEL
ZD201 HZS2B2TA
ZD701 HZ7B2
INDUCTOR
SIGN MODEL
L501 82µH
L801 EXCELSA35V
OSCILLATOR
FREQUENCY 4MHz
IC
SIGN MODEL
REG1 MC7805CT
IF-HIC IF-MODULE
MICON AX-8G10
REG2 HA17431PA
IC2 ULN2003A
PQ8 PC817C
IC401 EEPROM
MODEL RAC-07CHV1, RAC-09CHV1
SIGN
C201 4700P 1K C
TYPE
VOLTAGE
(V)
CAPACITANCE
(F)
RATING VALUE
CAPACITOR
TYPE C ••• CERAMIC CAPACITOR
D ••• ELECTROLYTIC CAPACITOR
F ••• FILM CAPACITOR
C202 –––
C203 220P 1K C
C204 0.056 50 F
C205 0.0047 50 F
C206 0.056 50 F
C207 2200P 250 C
C208 330 25 D
C209 100 10 D
C210 220 63 D
C211 4.7 50 D
C213 –––
C301 0.047 25 C
C302 0.047 25 C
C303 0.047 25 C
C304 0.1 50 C
C305 0.1 50 C
C306 0.1 50 C
C307 0.01 25 C
C308 0.1 50 C
C401 0.1 50 C
C501 0.22 50 F
C502 0.022 50 F
C503 150P 50 C
C504 0.068 50 F
C505 0.22 50 F
C506 0.01 AC250 C
C507 0.01 AC250 C
C508 4700P 50 C
C509 0.0047 50 F
C701 33 6.3 D
C801 0.56 AC250 F
C802 0.01 AC400 C
C803 0.01 AC400 C
C804 100 450 D
C806 –––
C807 –––
C901 1.5 400 F
