– 20 –
MAIN PARTS COMPONENT
THERMOSTAT
Thermostat Specifications
FAN MOTOR
Fan Motor Specifications
CONNECTION
20°C
(68°F)
75°C
(167°F)
RA = 348.16
RM = 284.61
RA = 423.40
RM = 346.12
RM
GRAY
RA
TEMPERATURE
°C (°F)
INDICATION
16
INDICATION
24
INDICATION
32
MODEL RAS-07CH1, RAS-09CH1
THERMOSTAT MODEL IC
ON 17.6 (63.7)
OFF 16.6 (61.8)
ON 25.6 (78.1)
OFF 24.6 (76.3)
ON 33.6 (92.5)
OFF 32.6 (90.7)
35V
5V
M
RED
YELLOW
BLUE
RESISTANCE VALUE
(
)
RED
INTERNAL
THERMAL FUSE
BLACK
CAPACITOR
–––––––
–––––––
MODEL RAS-07CH1 RAC-07CHV1
RAS-09CH1 RAC-09CHV1
PHASE ––––––– SINGLE
RATED VOLTAGE DC0 – 35 V 220 – 240 V
RATED FREQUENCY ––––––– 50 Hz
OUTPUT 20 W 20 W
POLE NUMBER ––––––– 6
