Hitachi RAD-50PPA - Names and Functions of each Part

– 4 –
NAMES AND FUNCTIONS OF EACH PART
INDOOR UNIT
MODEL NAME AND DIMENSIONS
OUTDOOR UNIT
MODEL WIDTH (mm) HEIGHT (mm) DEPTH (mm)
RAD-50PPA / RAD-60PPA / RAD-70PPA 900 270 720
RAC-50DPA / RAC-60DPA / RAC-70DPA 850 800 298
Suction grille
Discharge grille
FULL DUCT
SEMI DUCT NON DUCT
Air de ector
DRAIN PIPE
Condensed water drain to outside.
CONNECTING CORD
AIR INLET (BACK, LEFT SIDE)
AIR OUTLET
Discharge grille
Discharge grille
