AIR COOLED
WATER CHILLERS
-SCREW TYPE-
Installation, Operation and Maintenance Instructions.
Design Information
Technical Catalog
RCUE40AG1-400AG1 (R407C)
Cooling Capacity 108 kW - 1068 kW

Table of Contents

Questions and Answers

  • A
    Anna RodriguezAug 19, 2025
    How to fix a Hitachi Chiller when the condenser fan does not operate?
    • S
      Stephen MckeeAug 19, 2025
      If the condenser fan on your Hitachi Chiller isn't working, there are several potential causes: * The current to the unit may be shut off. Try resetting the power supply line. * The fuse for the operation circuit might be blown or have faulty contact. Check for shorted components or loose connections, and tighten or replace as needed. * The contactor holding coil could be burned out or have faulty contact. Identify the cause and repair or replace the coil. * The overcurrent relay may be tripped. Remove the cause and reset the relay. * There might be low voltage. Verify the unit's voltage rating. * The motor or terminals could be shorted. Inspect the motor and terminals, repairing or replacing them if necessary.
  • M
    Mitchell SmithAug 21, 2025
    What causes high discharge pressure in a Hitachi Chiller and how to resolve it?
    • R
      Roger WardAug 21, 2025
      High discharge pressure in your Hitachi Chiller can stem from several issues: * High condenser air temperature or insufficient airflow through the condenser. Check the fan operation and clean the coil if it's clogged. * A defective check valve or a partially closed liquid line valve. Inspect the valves, capillary tubes, and strainer, replacing them if necessary. * Overcharged refrigerant. Purge the excess refrigerant. * Air or non-condensable gas in the refrigerant cycle. Purge the gas. * Suction pressure is higher than standard. See “High Suction Pressure.”
  • J
    johnsonstevenAug 25, 2025
    What to do if the compressor does not operate on my Hitachi RCUE240AG1 Chiller?
    • J
      John PorterAug 25, 2025
      If the compressor on your Hitachi Chiller isn't operating, consider these possible causes: * The condenser fan may not be working. Address any issues with the fan. * The interlock circuit for the chilled water pump could be open. Check the pump contactor and the pump itself for faults, repairing or replacing parts as needed. * Electrical protective devices may have tripped. Identify and resolve the cause before resetting the “ON” button. * The wiring connection for the compressor power source may be incorrect. Interchange two of the three terminals (R, S, and T) at the main power source terminals.
  • N
    Nicole FloresAug 26, 2025
    Why is the suction pressure low in my Hitachi Chiller, and how can I fix it?
    • J
      John JosephAug 26, 2025
      Low suction pressure in your Hitachi Chiller can be caused by: * Low inlet temperature of chilled water. Check the installation specifications. * Improperly adjusted or faulty expansion valve. Adjust for correct superheat, or repair/replace the valve if necessary. * Insufficient refrigerant charge. Add refrigerant. * Excessive oil in the water cooler. Purge the oil. * Scales on water cooler plates. Clean the plates.
  • E
    ewilliamsonAug 28, 2025
    How to troubleshoot insufficient cooling in a Hitachi RCUE240AG1 Chiller?
    • C
      Charles ReidAug 28, 2025
      If your Hitachi Chiller isn't cooling sufficiently, check the following: * High discharge pressure or low suction pressure. Refer to the sections on “High Discharge Pressure” and “Low Suction Pressure.” * Improper thermostat setting. Readjust the thermostat. * Defective unload mechanism. Adjust the mechanism, and repair or replace any unloaded parts if needed.
  • S
    Savannah JarvisAug 30, 2025
    What causes a Hitachi RCUE240AG1 Chiller compressor to stop on an overcurrent relay?
    • E
      Eileen EdwardsAug 30, 2025
      A Hitachi Chiller compressor might stop due to the overcurrent relay tripping because of: * Excessively high discharge and suction pressure. Refer to “High Discharge Pressure” and “High Suction Pressure”. * High or low voltage, single-phase condition, or phase imbalance. Check the power supply line and contactors, repairing as necessary. * Loose connection. Tighten the loose electrical connection or repair it if needed. * Faulty compressor motor. Check the compressor motor and repair or replace it if necessary. * Faulty overcurrent relay. Replace the relay if necessary.
  • C
    Christopher JohnsonSep 1, 2025
    Why does the compressor stop on the freeze protection thermostat in my Hitachi Chiller?
    • K
      kimloriSep 1, 2025
      The compressor in your Hitachi Chiller might stop due to the freeze protection thermostat for these reasons: * Excessively low chilled water outlet temperature. Check for an excessively low setting on the chilled water setting knob. * Defective thermistor. Check for malfunction of the thermistor and replace it if necessary. * Shortage of chilled water flow. Check the rotation of the pump. * Air in the water circuit. Purge the air.
  • G
    Gina BellSep 3, 2025
    What could cause high suction pressure in a Hitachi RCUE240AG1?
    • W
      Wendy ParkerSep 3, 2025
      High suction pressure in a Hitachi Chiller can result from: * High inlet temperature of chilled water. Check the insulation of the piping and the installation specifications. * Excessive opening of the expansion valve. Readjust the opening or replace the valve if it's defective.
  • D
    Dana RichardsonSep 5, 2025
    Why does my Hitachi RCUE240AG1 compressor stop on the high pressure switch?
    • C
      Christopher MillerSep 5, 2025
      The Hitachi Chiller compressor may stop due to the high pressure switch for the following reasons: * Excessively high discharge pressure. See “High Discharge Pressure”. * Malfunction of the high pressure switch. Readjust the setting or replace it if defective.
  • M
    Melissa ReyesSep 7, 2025
    What causes the compressor to stop on the internal thermostat in a Hitachi Chiller?
    • S
      Steven BakerSep 7, 2025
      The compressor in your Hitachi Chiller may stop on the internal thermostat or discharge gas thermostat due to: * High or low voltage, single-phase condition, or phase imbalance. Check the power supply line and contactor, repairing if necessary. * Excessive superheat. Check for refrigerant leakage and a faulty solenoid valve for liquid bypass. * Defective element. Check the contact of the internal thermostat during the cold condition. * Excessive high discharge pressure and low suction pressure. See “High Discharge Pressure” and “Low Suction Pressure.”

Summary

IMPORTANT NOTICE

FEATURES AND BENEFITS

COMPRESSOR TECHNOLOGY

Details about the twin screw compressor technology, its components, and principle of operation.

CONTROL SYSTEM FUNCTIONS

OPERATION INSTRUCTIONS

CHILLER OPERATION

INITIAL CHECK AND PREPARATION

PRE-INSTALLATION CHECKS

UNIT PLACEMENT AND HANDLING

INSTALLATION SPACE AND FOUNDATION

INSTALLATION GUIDELINES

ELECTRICAL WIRING PROCEDURES

Procedures and precautions for main power and control wiring, including earthling.

WATER PIPING CONNECTIONS

Guidelines and recommendations for connecting water piping to the unit, including insulation.

TYPICAL WATER PIPING DIAGRAMS

BMS SYSTEM INTEGRATION

FINAL INSTALLATION CHECKLIST

A checklist for verifying all installation aspects are completed correctly.

TEST RUNNING PROCEDURES

CONDUCTING THE TEST RUN

Step-by-step procedure for conducting the test run of the chiller unit.

CONTROLLER SETTINGS AND ADJUSTMENT

CONTROL SYSTEM OVERVIEW

Overview of the control system, capacity control, and control panel functions.

DETAILED CONTROLLER SETTINGS

Detailed settings for various controller parameters like temperature and mode.

SELF-INSPECTION AND MONITORING

ALARM CODE INDICATION

Explains alarm codes and their meanings displayed on the control panel.

STANDARD OPERATION SEQUENCES

MAINTENANCE PROCEDURES

CLEANING METHOD DETAILS

Detailed procedure for cleaning the water chiller's heat exchangers and piping.

SEASONAL SHUTDOWN AND START-UP

REFRIGERANT CYCLE SERVICE

Procedures for checking and charging the refrigerant system.

COMPRESSOR REMOVAL STEPS

SAFETY AND PROTECTION CONTROLS

Details on safety devices and their settings for compressor and fan motors.

NORMAL OPERATING PRESSURE CHECK

R407 C REFRIGERANT SYSTEM SERVICING

Specific servicing instructions and precautions for R407C refrigerant.

TROUBLESHOOTING GUIDE

FAULT DIAGNOSIS AND CORRECTION

Table listing faults, possible causes, and corrective actions for common issues.

TECHNICAL DRAWINGS

DIMENSIONAL DRAWINGS

WIRING DIAGRAMS

Schematics illustrating the power and control circuit wiring for the unit.

MODEL SELECTION GUIDANCE

SELECTION EXAMPLE WALKTHROUGH

PERFORMANCE TABLES (R407 C)

Tables showing performance data like capacity, input, and COP for various models.

ELECTRICAL DATA TABLES

Electrical specifications including voltage, current, and power for each model.
