AIR COOLED
WATER CHILLERS
-SCREW TYPE-
Installation, Operation and Maintenance Instructions.
Design Information
Technical Catalog
RCUE40AG1-400AG1 (R407C)
Cooling Capacity 108 kW - 1068 kW

Table of Contents

Questions and Answers

  • F
    fwatsonAug 19, 2025
    How to fix a Hitachi Chiller when the condenser fan does not operate?
    • M
      Maria WongAug 19, 2025
      If the condenser fan on your Hitachi Chiller isn't working, there are several potential causes: * The current to the unit may be shut off. Try resetting the power supply line. * The fuse for the operation circuit might be blown or have faulty contact. Check for shorted components or loose connections, and tighten or replace as needed. * The contactor holding coil could be burned out or have faulty contact. Identify the cause and repair or replace the coil. * The overcurrent relay may be tripped. Remove the cause and reset the relay. * There might be low voltage. Verify the unit's voltage rating. * The motor or terminals could be shorted. Inspect the motor and terminals, repairing or replacing them if necessary.
  • E
    Erin HarperAug 21, 2025
    What causes high discharge pressure in a Hitachi Chiller and how to resolve it?
    • M
      Marcus HernandezAug 21, 2025
      High discharge pressure in your Hitachi Chiller can stem from several issues: * High condenser air temperature or insufficient airflow through the condenser. Check the fan operation and clean the coil if it's clogged. * A defective check valve or a partially closed liquid line valve. Inspect the valves, capillary tubes, and strainer, replacing them if necessary. * Overcharged refrigerant. Purge the excess refrigerant. * Air or non-condensable gas in the refrigerant cycle. Purge the gas. * Suction pressure is higher than standard. See “High Suction Pressure.”
  • W
    William KramerAug 23, 2025
    What to do if the compressor does not operate on my Hitachi RCUE200AG1?
    • A
      Amanda JohnsonAug 25, 2025
      If the compressor on your Hitachi Chiller isn't operating, consider these possible causes: * The condenser fan may not be working. Address any issues with the fan. * The interlock circuit for the chilled water pump could be open. Check the pump contactor and the pump itself for faults, repairing or replacing parts as needed. * Electrical protective devices may have tripped. Identify and resolve the cause before resetting the “ON” button. * The wiring connection for the compressor power source may be incorrect. Interchange two of the three terminals (R, S, and T) at the main power source terminals.
  • P
    pdavisAug 26, 2025
    Why is the suction pressure low in my Hitachi RCUE200AG1 Chiller, and how can I fix it?
    • C
      Cameron SparksAug 27, 2025
      Low suction pressure in your Hitachi Chiller can be caused by: * Low inlet temperature of chilled water. Check the installation specifications. * Improperly adjusted or faulty expansion valve. Adjust for correct superheat, or repair/replace the valve if necessary. * Insufficient refrigerant charge. Add refrigerant. * Excessive oil in the water cooler. Purge the oil. * Scales on water cooler plates. Clean the plates.
  • T
    Tammy SharpAug 28, 2025
    How to troubleshoot insufficient cooling in a Hitachi RCUE200AG1?
    • M
      Marc SandovalAug 28, 2025
      If your Hitachi Chiller isn't cooling sufficiently, check the following: * High discharge pressure or low suction pressure. Refer to the sections on “High Discharge Pressure” and “Low Suction Pressure.” * Improper thermostat setting. Readjust the thermostat. * Defective unload mechanism. Adjust the mechanism, and repair or replace any unloaded parts if needed.
  • D
    Daniel BenjaminAug 30, 2025
    What causes a Hitachi RCUE200AG1 Chiller compressor to stop on an overcurrent relay?
    • A
      Alicia RichardsAug 30, 2025
      A Hitachi Chiller compressor might stop due to the overcurrent relay tripping because of: * Excessively high discharge and suction pressure. Refer to “High Discharge Pressure” and “High Suction Pressure”. * High or low voltage, single-phase condition, or phase imbalance. Check the power supply line and contactors, repairing as necessary. * Loose connection. Tighten the loose electrical connection or repair it if needed. * Faulty compressor motor. Check the compressor motor and repair or replace it if necessary. * Faulty overcurrent relay. Replace the relay if necessary.
  • J
    Jennifer JohnsonSep 1, 2025
    Why does the compressor stop on the freeze protection thermostat in my Hitachi Chiller?
    • J
      Jason SullivanSep 1, 2025
      The compressor in your Hitachi Chiller might stop due to the freeze protection thermostat for these reasons: * Excessively low chilled water outlet temperature. Check for an excessively low setting on the chilled water setting knob. * Defective thermistor. Check for malfunction of the thermistor and replace it if necessary. * Shortage of chilled water flow. Check the rotation of the pump. * Air in the water circuit. Purge the air.
  • A
    Andrew BakerSep 3, 2025
    What could cause high suction pressure in a Hitachi RCUE200AG1 Chiller?
    • J
      James HowellSep 3, 2025
      High suction pressure in a Hitachi Chiller can result from: * High inlet temperature of chilled water. Check the insulation of the piping and the installation specifications. * Excessive opening of the expansion valve. Readjust the opening or replace the valve if it's defective.
  • J
    Jeffrey CunninghamSep 5, 2025
    Why does my Hitachi Chiller compressor stop on the high pressure switch?
    • J
      Jessica OdonnellSep 5, 2025
      The Hitachi Chiller compressor may stop due to the high pressure switch for the following reasons: * Excessively high discharge pressure. See “High Discharge Pressure”. * Malfunction of the high pressure switch. Readjust the setting or replace it if defective.
  • L
    lindathompsonSep 7, 2025
    What causes the compressor to stop on the internal thermostat in a Hitachi RCUE200AG1?
    • A
      ann39Sep 7, 2025
      The compressor in your Hitachi Chiller may stop on the internal thermostat or discharge gas thermostat due to: * High or low voltage, single-phase condition, or phase imbalance. Check the power supply line and contactor, repairing if necessary. * Excessive superheat. Check for refrigerant leakage and a faulty solenoid valve for liquid bypass. * Defective element. Check the contact of the internal thermostat during the cold condition. * Excessive high discharge pressure and low suction pressure. See “High Discharge Pressure” and “Low Suction Pressure.”
