Hitachi SRL Series User Manual

Introduction
The instruction manual gives details related to the specifications, construction, installation, operation,
maintenance and inspection of the Oilfree Scroll Air Compressor.
This instruction manual describes the proper operation method to smoothly and safely utilize the
functions of the Oilfree Scroll Air Compressor.
Table of Contents
1
● Daily Operating Components
● Installation
1. Product Confirmation
2. Transporting the Air compressor
3. Installing the Air compressor
4. Piping the Air compressor
5. Wiring the Air compressor
● Operation
1. Control Panel Descriptions
2. Prior to Operation
3. Start Up
4. Daily Operation
● Maintenance and Inspection
● Troubleshooting
● Parts List
● Wiring Diagram
● Standard Specifications
● Aftermarket Ordering Procedure
・・・・・・・・・・ 2
・・・・・・・・・・ 4
・・・・・・・・・・ 4
・・・・・・・・・・ 4
・・・・・・・・・・ 5
・・・・・・・・・・ 7
・・・・・・・・・・ 8
・・・・・・・・・・ 12
・・・・・・・・・・ 12
・・・・・・・・・・ 14
・・・・・・・・・・ 19
・・・・・・・・・・ 20
・・・・・・・・・・ 21
・・・・・・・・・・ 29
・・・・・・・・・・ 33
・・・・・・・・・・ 34
・・・・・・・・・・ 36
・・・・・・・・・・ 37
Safety Precautions (continued)
● If the air compressor has not run in over one (1) month, carry out the long term storage operation
prior to restarting the air compressor (See page 28).
Failure to adhere to this precaution may cause abnormal wear to the air compressor components, damage to the air
compressor and/or accidents.
● Verify that the front door chain has been connected before closing the door.
● Make sure the V-belt is tightened properly prior to operation. If the V-belt is loose, tighten the V-belt
prior to operation.
Failure to adhere to this precaution may cause belt slippage, damage to the air compressor and/or excessive noise.
CAUTION

Hitachi SRL Series Specifications

General

Brand	Hitachi
Model	SRL Series
Category	Air Compressor
Language	English
