Daily Operating Components
2
Air Compressor Exterior
● Do not leave the front door open during operation.
Failure to adhere to this precaution may cause dust to be ingested, excessive vibration and/or noise to be
generated and/or reduction in air compressor life due to excessive temperature rise.
CAUTION
Air Exhaust
Air Intake
● Intake air and cooling
air is supplied to the air
compressor.
Compressed Air
Discharge Pipe
Power Cable Inlet
Control Panel
Locks for door
enclosure with Keys
Front Door
Emergency Stop
Switch
SRL-7.5M6LL/ML/LH/MH
SRL-11M6LL/ML/LH/MH
SRL-16.5M6LL/ML/LH/MH
● Make sure that front
door is closed during
the operation of the air
compressor.
Air Exhaust
Air Intake
● Intake air and cooling
air is supplied to the air
compressor.
Compressed Air
Discharge Pipe
Power Cable Inlet
Control Panel
Locks for door
enclosure with Keys
Front Door
Emergency Stop
Switch
● Make sure that front
door is closed during
the operation of the air
compressor.
