Hitachi SRL Series User Manual

Daily Operating Components(continued)
3
Air Compressor Interior
Check Valve
Scroll Head
Air Release Valve
Power Supply Panel
Electric Main Motor
Rubber Vibration
Isolators
V-BeltPrimary Cooler
Ventilating Fan
SRL-7.5M6LL/ML/LH/MH
SRL-11M6LL/ML/LH/MH
SRL-16.5M6LL/ML/LH/MH
Safety Relief Valve
Rubber Hose
Intake Air Filter
● 10HP (7.7kW) : 3 locations
● 15HP (11kW) : 4 locations
Transport Fixture
● 2 locations
Secondary Cooler
Main Power Supply
Terminal Block
Electromagnetic
Contactor
Check Valve
Scroll Head
Air Release Valve
Power Supply Panel
Electric Main Motor
Rubber Vibration
Isolators
V-Belt
Primary Cooler
Ventilating Fan
Safety Relief Valve
Rubber Hose
Intake Air Filter
● 6 locations
Transport Fixture
● 3 locations
Secondary Cooler
Main Power Supply
Terminal Block
Electromagnetic
Contactor
Ventilating Fan
