Bandwidth
Rise time
Input impedance
Input coupling
Max. Input voltage
Input connector
CHI output
Output voltage*
Bandwidth*
Output Noise*
2.5 times on each position
with variable control)
* ImV - IV/div (using x5 GAIN)
DC to, 15MHz
DC to 5MHz (using x5 GAIN)
Typical 24ns
IMn shunted by 30pF +5pF
(direct)
AC, GND, DC
600Vp-p, 300V (DC+AC peak)
BNC
20mV/div Min.
50Hz-5MHz(-3dB)(at xl GAIN)
lOmVp-p Max.
* Measured by Im 50-ohm BNC Cable with 50—ohm
terminator.
Approx. 50f2
AC
Output impedance
Output coupling
Time base
Sweep speed
Magnification
X-Y display
0.2us - 0.2s/div
19 step, 1-2-5 sequence
xlO (max speed 100 ns/div)
X=EXT. TRG or \Y\ IN, Y=INPUT
Sensitivity Y axis: 5mV/div - 5V/div
X axis: approx. 0.2V/div
Bandwidth X axis: DC 500 kHz
X-Y phase shift Less than 3° at 10 kHz
Synchronization
Trigger sensitivity
Frequency
INT. trig
EXT. trig
20Hz ~ 2MHz
0.5DIV
200 mV
2MHz - 15MHz
1.5DIV
800 mV
MODE
Source
NORMal trigger and AUTO-
matic trigger Automatic
(sweep free-run)
Normal (sweep runs when
triggered)
TV(+), TV(-)
Extracts the synchronizing
signal from composite video
signal and provides stable
synchronization. Slope
switch is selected accord
ing to polarity of video
signals.
INTernal or EXTernal, or
LINE.
