9. Find the washers, O-rings, and screws included with the bezel bracket mounting kit (part number
043-100885-01.P). Then install a washer, O-ring, and screw (one per side) between the mounting profile of the
rack and the mounting "ears" of the controller. The screw engages the threaded hole in the rail.
Item Description
1 Screw
2 O-ring
3 Washer
The rack installation for your controller should resemble the following figure.
Item Description
1 Washers, O-rings, and screws securing the controller to the front of the rack
Parent Topic
• Installing your VSP G130 storage system
