ENGLISH
Heating Source
REF Access Description
Default
Value
Range Steps Units Application
Notes
Heating Source S SC S80 M
HES Heating source HP Only
HP Only
HP + Heater
HP + Boiler
HP + Heat. + Boil.
- - ○ ○ ○ ○ (*1)
? NOTE
(*1): “HP+Heat+Boil” is not available for YUTAKI S80 and M.
Electrical Heater
REF Access Description
Default
Value
Range Steps Units Application
Notes
Electrical Heater S SC S80 M
HEBP
Bivalent Point 0 -20~20 1 ºC ○ ○ ○ ○ (*1)
HEksco
Supply Setting Offset 4 0 ~10 1 K ○ ○ ○ ○
HEPB Proportional Band 6.0 0~20 0.2 ºC/100% ○ ○ ○ ○
HEIRF Reset Factor 2.5 0~20 0.1 %/ºCmin ○ ○ ○ ○
HEISWT Inter Stage Time 5 1~10 1 min ○ ○ ○ ○
HEWTEH Waiting Time 30 5~90 5 min ○ ○ ○ ○
? NOTE
(*1): If Heating source (HES)= “HP+Heat.+Boil.”, the bivalent point for electric heater must be equal or higher than the bivalent point for boiler + 5 ºC of
offset (Bivalent point (HEBP) ≥ Bivalent point (BOBP) + 5 ºC)
Boiler Combination
REF Access Description
Default
Value
Range Steps Units Application
Notes
Boiler Combination
S SC S80 M
BOBP Bivalent Point -5 -20~20 1 ºC ○ ○ ○ ○ (*1)(*2)
BOCM Combination mode Parallel Parallel / Serie - - ○ ○ ○ ○
BOksco Supply Setting Offset 4 0~10 1 ºC ○ ○ ○ ○
BOon Minimum ON Time 2 1~30 1 min ○ ○ ○ ○
BOoff Minimum OFF Time 5 1~30 1 min ○ ○ ○ ○
BOWt Waitting Time 30 5~90 5 min ○ ○ ○ ○
BODHW DHW by Boiler Disabled
Disabled /
Enabled
- - ○ - ○ ○ (*3)
BODWt Wait Time for DHW 45 OFF, 5~120 5 min ○ - ○ ○ (*3)
? NOTE
• (*1): If Heating source (HES)= “HP+Heat.+Boil.”, Bivalent point (BOBP) has a range withing -15 and 20ºC.
• (*2): If Heating source (HES)= “HP+Heat.+Boil.”, the bivalent point for electric heater must be equal or higher than the bivalent point for boiler + 5
ºC of offset (Bivalent point (HEBP) ≥ Bivalent point (BOBP) + 5 ºC).
• (*3): If Status (DHWs)= “Enabled”. This parameter is not displayed in case of YUTAKI S80 (Version for combination with DHW).
UNIT CONTROLLER
PMML0335A rev.1 - 04/2016
153
