7-56
MAINTENANCE
9.
After replacing the filter
, bleed air from the h
ydraulic
pump and check the oil level in the hy
draulic oil tank.
(Refer to the descriptions for "Bleed air fr
om the
hydr
aulic system" in item
.)
If the machine is operated without bleeding the air
mixed in the h
ydraulic circuit, damage t
o the hydraulic
pump may result.
f
NO
TE:
Replace the element at the regular int
er
vals to
maintain clean hydr
aulic oil and extend the ser
vice life of the
hydr
aulic components.
