10
DEPLOYING THE GRILL
A. Pull out and twist the hinge spring lock.
B. Release the slam-latch by pressing down
on the lever.
Swing the swing-away arm and grill away
from the vehicle.
Rotate the hinge spring lock to lock the
arm’s position at either 90 or 180 degrees.
Remove the padlock (not included) that
locks the collar to the arm. Loosen the
rotation knob on the arm collar.
Rotate the grill head to the desired position
and tighten rotation knob on the arm collar.
Follow the cooking instructions on the next
page.
1 2
4
3
A
B
To Next Page
